3500/42_SIL2-04-CN Proximitor Seismic Monitor by Bently Nevada: Overview, Features, and Technical Specifications

The 3500/42M Proximitor Seismic Monitor is designed to protect machinery by continuously monitoring critical parameters and generating alarms when setpoints are exceeded. It provides essential data for both operational and maintenance personnel to ensure that machinery performance is optimized.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3500/42_SIL2-04-CN
• Power Consumption: 7.7 watts (typical)
• Input Impedance: 10 kΩ (Standard I/O for Proximitor and acceleration inputs)
• Signal Sensitivity:
  • Radial Vibration: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
  • Thrust Position: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
  • Eccentricity: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
  • Differential Expansion: 0.394 mV/μm (10 mV/mil) or 0.787 mV/μm (20 mV/mil)
  • REBAM: 40 mV/μm (1000 mV/mil) or 80 mV/μm (2000 mV/mil)
  • Acceleration: 10 mV/(m/s²) (100 mV/g)
  • Velocity: 20 mV/(mm/s) pk (500 mV/(in/s) pk) or 5.8 mV/(mm/s) pk (145 mV/(in/s) pk)
  • Shaft Absolute (Radial Vibration): 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
  • Shaft Absolute (Direct): 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
  • Shaft Absolute (Velocity): 20 mV/(mm/s) pk (500 mV/(in/s) pk) or 5.8 mV/(mm/s) pk (145 mV/(in/s) pk)

Frequently Asked Questions (FAQ)

Q1: How many channels does the 3500/42M support?
A1: The 3500/42M supports up to four channels, each capable of monitoring different parameters like vibration, position, and acceleration.

Q2: Can the 3500/42M be configured remotely?
A2: Yes, the 3500/42M can be configured using the 3500 Rack Configuration Software, which allows remote programming of each channel.

Q3: What kind of transducer signals can the 3500/42M accept?
A3: The 3500/42M accepts input from proximity, velocity, and acceleration transducer signals, providing versatile monitoring options.

Q4: Is the 3500/42M suitable for harsh environments?
A4: Yes, the 3500/42M is designed to function effectively in industrial environments with demanding conditions, providing reliable machinery protection.
