8 mm Proximity Probe Bently Nevada 330104-00-08-10-02-05

Overview

The Bently Nevada 3300 XL 8 mm Proximity Probe is a high-precision, durable sensor engineered for advanced vibration monitoring and machinery protection applications. Its robust construction, reliable materials, and superior performance ensure optimal operation in industrial environments. This model, 330104-00-08-10-02-05, includes CSA, ATEX, and IECEx approvals, making it suitable for use in hazardous areas.

Technical Specifications

• Brand: Bently Nevada
• Model: 330104-00-08-10-02-05
  • 00: Unthreaded length, 0 mm
  • 08: Case length, 80 mm
  • 10: Probe length, 1.0 meter
  • 02: Connector type, ClickLoc standard cable
  • 05: Approvals, CSA, ATEX, IECEx

Electrical Specifications:

• Power Supply: -17.5 Vdc to -26 Vdc
• Consumption: 12 mA maximum
• Sensitivity: Less than 2 mV change per volt variation in input voltage
• Output Resistance: 50 Ω

Environmental Specifications:

• Standard Temperature Range: -52°C to +177°C (-62°F to +350°F)
• Extended Temperature Range: Up to +218°C (+425°F) for probe tip, +260°C (+500°F) for cable and connector
• Humidity Resistance: Minimal impact on ASF under 93% humidity, as per IEC 68 2 3 standards

Mechanical Properties:

• Weight: 0.323 kg
• Patented CableLoc and TipLoc designs for improved durability
• FluidLoc option available to prevent liquid ingress

FAQs

1. What approvals does this model have?
   This model is certified with CSA, ATEX, and IECEx approvals, ensuring compliance with safety standards in hazardous environments.
2. Can this probe handle extreme temperatures?
   Yes, the extended temperature range version supports up to +218°C at the probe tip and +260°C for the cable and connector.
3. What is the purpose of the FluidLoc option?
   FluidLoc prevents oil or liquids from leaking through the cable, enhancing reliability in fluid-heavy applications.
4. Is pressure testing available for this model?
   Probes are not pressure-tested before shipment. Custom testing services are available upon request.
5. What materials are used in its construction?
   The probe tip is made of Polyphenylene sulfide (PPS), and the case is constructed with AISI 303/304 stainless steel for durability.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
