9200-01-50-01-04 | Two-wire Velocity Seismoprobe Transducer

Overview:

The Bently Nevada 9200-01-50-01-04 is a Two-Wire Velocity Seismoprobe Transducer designed for monitoring vibration levels. It features advanced capabilities for detecting displacement and velocity in industrial machinery. The sensor is equipped with ATEX/IECEx approvals, making it suitable for use in hazardous environments.

Features:

• Connector Option: 50 feet (15.2 meters) of integral hardline cable for secure connection.
• Mounting Base: Circular 1/4-20 UNC stud for easy installation.
• Agency Approval: ATEX/IECEx certified for safe operation in hazardous areas.
• Material: Anodized aluminum A204 for robust protection against environmental factors.
• Polarity of Output Signal: Pin A is positive relative to Pin B when the transducer case moves towards the connector.
• Environmental Limits: Operating and storage temperature range of -29°C to +121°C (-20°F to +250°F).
• Shock Resistance: Can withstand up to 50 g peak maximum acceleration along a non-sensitive axis.

Technical Specifications:

• Model: Bently Nevada 9200-01-50-01-04
• Height: 102 mm (4 inches) typical, depending on the connector option.
• Diameter: 41 mm (1.6 inches) typical.
• Weight: 300 grams (10.5 ounces) typical.
• Frequency Response: 4.5 to 1000 Hz (270 to 60,000 CPM); +0, -3 dB typical.
• Sensitivity: 20 mV/mm/s (500 mV/in/s), ±5% when terminated and oriented at the calibration angle.
• Shock Resistance: 50 g peak acceleration along non-sensitive axis.
• Coil Resistance: 1.25 kΩ ±5%.
• Inductance: 125 mH typical.
• Maximum Displacement: 2.54 mm (0.100 in) peak to peak.

FAQ:

1. What is the maximum operating temperature for the Bently Nevada 9200 transducer?
   The maximum operating temperature is +121°C (+250°F).
2. Can this transducer be used in hazardous locations?
   Yes, it has ATEX/IECEx certification for use in hazardous environments.
3. What is the maximum length of cable that can be used with the Seismoprobe?
   The maximum cable length is 305 meters (1,000 feet), but consult the manual for frequency roll-off at longer distances.
4. What is the maximum shock resistance of the Bently Nevada 9200?
   The transducer can withstand up to 50 g peak maximum acceleration.

Check official datasheet for more detailed information:9200 and 74712 Seismoprobe Velocity Transducers Datasheet
