990-05-70-01-00 Bently Nevada | 990 Vibration Transmitter

Technical Specifications:

• Brand: Bently Nevada
• Model: 990-05-70-01-00
• Suffix Code Meaning:
  • 05 – Full-scale range: 0-5 mils pp (0-125 μm pp)
  • 70 – System length: 7.0 meters (23.0 feet)
  • 01 – Mounting option: 35 mm DIN rail clips
  • 00 – Agency approval: Not required
• Operating Temperature: -35°C to +85°C (-31°F to +185°F)
• Storage Temperature: -52°C to +100°C (-62°F to +212°F)
• Transducer Tip: Polyphenylene sulfide (PPS)
• Transducer Case: AISI 303 or 304 Stainless Steel (SST)
• Probe Cable: 75Ω coaxial, fluoroethylene propylene (FEP) insulated
• Cable Armor (Optional): Flexible AISI 302 SST with optional FEP outer jacket
• Tensile Strength: 222 N (50 lbf) maximum
• Weight: 0.43 kg (0.9 lbm) for the transmitter, 0.82 kg (1.8 lbm) for the system

FAQ:

1. What is the full-scale range of the Bently Nevada 990-05-70-01-00?
   • The full-scale range is 0-5 mils pp (0-125 μm pp), designed for precise vibration measurement.
2. What is the system length option?
   • The system length option is 7.0 meters (23.0 feet), providing flexibility in installation.
3. What is the operating temperature range?
   • The operating temperature range is -35°C to +85°C (-31°F to +185°F), ensuring functionality in various environments.
4. Is agency approval required for this product?
   • No, agency approval is not required for the 990-05-70-01-00 model.
5. What materials are used in the construction?
   • The transducer tip is made of Polyphenylene sulfide (PPS), and the transducer case is made of AISI 303 or 304 Stainless Steel (SST).

For more detailed information:990 Vibration Transmitter Datasheet
