990-08-XX-01-CN Bently Nevada | Two-wire Vibration Transmitter

Technical Specifications for 990-08-XX-01-CN:

• Brand: Bently Nevada
• Model: 990 Vibration Transmitter 990-08-XX-01-CN
• Suffix: CN (Country-Specific Agency Approval)
• Full-Scale Range: 0-8 mils pp (0-200 μm pp)
• System Length Options:
  • 50 (5.0 meters / 16.4 feet)
  • 70 (7.0 meters / 23.0 feet)
• Mounting Option: 35 mm DIN rail clips
• Frequency Response: 5 Hz to 6,000 Hz ±0.3 dB
• Input: 1 non-contacting 3300 NSv Proximity Probe with extension cable
• Power Supply: 12-35 Vdc input
• Signal Output: 4-20 mA output
• Loop Resistance: Maximum 1,000 Ω including cable at 35 Vdc
• Probe Gap: 0.5 mm to 1.75 mm (20 mils to 55 mils)
• Weight: 0.43 kg (0.9 lbm)

Frequently Asked Questions (FAQ):

1. Q: What is the full-scale range of the Bently Nevada 990 Transmitter?
2. A: The full-scale range is 0-8 mils pp (0-200 μm pp).
3. Q: What types of materials are used for the probe case?
4. A: The probe case is made of AISI 303 or AISI 304 stainless steel.
5. Q: Can the 990 Vibration Transmitter be used in hazardous locations?
6. A: Yes, it is certified for use in non-hazardous, Zone 2, or Div 2 hazardous area locations.
7. Q: What is the maximum loop resistance for the 990 Transmitter?
8. A: The maximum loop resistance is 1,000 Ω including the cable at 35 Vdc.
9. Q:What is the temperature range of the Bently Nevada 990 Vibration Transmitter?
10. A:The operating temperature ranges from -35°C to +85°C (-31°F to +185°F), and the storage temperature ranges from -52°C to +100°C (-62°F to +212°F).
11. Q:What is the weight of the Bently Nevada 990 Vibration Transmitter?
12. A:The transmitter weighs 0.43 kg (0.9 lbm).

For more detailed information:990 Vibration Transmitter Datasheet
