991 Thrust Transmitter 991-06-70-01-00 Bently Nevada

991 Thrust Transmitter 991-06-70-01-00 Bently Nevada

Key Features:

• Brand: Bently Nevada
• Model: 991-06-70-01-00
• Type: Thrust Transmitter
• Made in the USA: Yes
• Certification: Can include a Certificate of Origin (COO)
• Mounting: 35 mm DIN-rail clips
• Agency Approval: Not required
• Full-scale Range: 0.6 mm (±0.6 mm)
• System Length: 7.0 meters (23 feet)

Technical Specifications:

• Power Supply: 12 to 35 Vdc input at the transmitter terminal
• Output Signal: 4 to 20 mA in 2-wire configuration
• Loop Resistance: Maximum 1,000 Ω including cable at 35 Vdc
• Current Limiting: 23 mA typical
• Accuracy: ±1.5% over the specified full-scale range (typical)
• Transducer Tip Material: Polyphenylene sulfide (PPS)
• Transducer Case Material: AISI 303/304 Stainless Steel (SST)
• Probe Cable: 75 Ω coaxial, FEP insulated
• Optional Cable Armor: Flexible AISI 302 SST with FEP outer jacket
• Transmitter Weight: 0.43 kg (0.9 lbm)
• Temperature Stability: Within ±10% of the incremental scale factor from 0°C to +70°C (+32°F to +158°F)
• Linear Range: 0.25 to 1.65 mm (10 to 65 mils)
• Proximitor Sensor Output Impedance: 10 kΩ for 10 MΩ load
• Minimum Target Size: 9.5 mm (0.375 in) diameter
• Leadwire Length: Maximum 3 meters (10 feet) for Proximitor Sensor Output

FAQ:

1. What is the output signal for the Bently Nevada 991-06-70-01-00 Thrust Transmitter? The output signal is a 4 to 20 mA signal in a 2-wire configuration.
2. What is the full-scale range for this transmitter? The full-scale range is 0.6 mm, with an accuracy of ±1.5% over the specified range.
3. What is the required power input? The transmitter requires a DC input of 12 to 35 Vdc.
4. What materials are used in the probe and transducer? The transducer tip is made of Polyphenylene sulfide (PPS), while the case is AISI 303/304 stainless steel.
5. What is the maximum loop resistance? The maximum loop resistance is 1,000 Ω, including the cable at 35 Vdc.
6. How far can the transmitter and receiving device be apart? For non-hazardous locations, the distance can be up to 13 km (8 miles).

For more detailed information:991 Thrust Transmitter Datasheet
