ABB 07-DI-93-I Digital Input Module 07DI93-I

Overview:

The ABB 07-DI-93-I is a digital remote unit designed for distributed automation I/O systems. It features 16 digital inputs with 24V DC operation and comes with IP67 protection, making it ideal for harsh industrial environments. It is part of the AC31 S90 family, ensuring robust and reliable operation for fieldbus communication.

Features:

• 16 Digital Inputs: 24V DC
• Protection: IP67, ensuring durability in dusty or wet conditions.
• Bus Module: CS31 Slave interface, suitable for use in industrial fieldbus systems.
• Compact Design: With dimensions of 70.5 mm depth, 80 mm width, and 230 mm height, it’s perfect for space-constrained installations.
• Environmentally Protected: Operating temperature from 0 to +55°C and storage temperature from -25 to +75°C.
• RS-485, CS31 Interface: Ensures effective communication within the automation system.

Technical Specifications:

• Brand: ABB
• Model: 07DI93-I/07-DI-93-I
• Part Number: GJV3075613R0202
• Type Designation: 07DI93-I
• Power Supply: 24 V DC
• Protection: IP67
• Temperature Range: Operation: 0 … +55 °C, Storage: -25 … +75 °C
• Fieldbus Interface: CS31 Slave
• Ambient Temperature: 0 … +55 °C
• Storage Temperature: -25 … +75 °C
• Gross Weight: 0.47 kg
• Dimensions: Depth 70.5 mm, Width 80 mm, Height 230 mm
• Customs Tariff Number: 85049099
• Certificate: ABS, RINA, RoHS

FAQ:

1. What is the degree of protection for the 07DI93-I?
   • The unit has an IP67 protection rating, making it highly resistant to dust and water ingress.
2. How many digital inputs does the 07DI93-I have?
   • The module provides 16 digital inputs for 24V DC signals.
3. What is the operating temperature range of the unit?
   • The unit operates within a temperature range of 0 … +55°C.
4. Is the unit suitable for outdoor use?
   • Yes, with its IP67 rating, the module is ideal for harsh outdoor conditions.
5. What is the fieldbus interface for the 07DI93-I?
   • The unit supports the CS31 Slave fieldbus interface for communication.

For more detailed information, please check official datasheet: Advant Controller 31
