ABB 07DO90-S Digital Output Unit 07-DO-90-S

Overview:

The 07-DO-90-S Safety Remote Unit by ABB is a digital output module designed for safety applications in industrial automation. It offers 8 transistor outputs with 24 V DC / 0.5 A capacity, providing reliable control for various systems. The module operates on the CS31 safety-bus, integrating seamlessly into safety-critical environments, making it ideal for applications requiring high reliability and safety standards.

Key Features:

• Safety Module: Designed specifically for safety applications.
• Outputs: 8 digital outputs, each rated for 24 V DC / 0.5 A.
• Fieldbus Interface: CS31 safety-bus Slave for secure communication.
• Power Supply: 24 V DC.
• Protection: Degree of protection IP20.
• Temperature Range: Operates between 0°C to 55°C, storage from -25°C to 75°C.
• Certificates: ABS, CSA, GL, DNV, LR, and RINA certified for compliance in various regions.
• Mounting: DIN rail mounted (35 x 15 mm or 35 x 7.5 mm rail).

Technical Specifications:

• Product Type: 07DO90-S/07-DO-90-S
• Product ID: GJR5250800R0202
• Power Supply: 24 V DC
• Output Voltage: 24 V DC
• Output Current: 0.5 A per output
• Number of Outputs: 8
• Fieldbus Interface: CS31-Bus
• Degree of Protection: IP20
• Ambient Air Temperature: 0 … +55 °C (operating), -25 … +75 °C (storage)
• Certification: CE, RoHS compliant
• Weight: 0.7 kg
• Dimensions: 85 mm depth, 120 mm width, 140 mm height
• Cable Cross-Section: 0.08 … 1.5 mm²

FAQ:

• Q: What is the output current capacity of each digital output?
• A: Each output can handle a maximum current of 0.5 A.
• Q: What are the mounting options?
• A: The module can be mounted on DIN rails TH35-15 or TH35-7.5 as per IEC 60715.
• Q: Is this module CE certified?
• A: Yes, it complies with CE certification.
• Q: What is the operating temperature range?
• A: The operating temperature range is 0°C to 55°C.

For more detailed information, please check official datasheet: Advant Controller 31
