Product details
PP885 3BSE069276R1 15.4″ Touch Display Overview
The PP885 3BSE069276R1 is a highly versatile and robust 15.4″ touch display designed for industrial and commercial applications. Featuring a durable polyester-on-glass resistive touchscreen, the PP885 offers excellent performance with its wide range of connectivity options and high-quality display. It is ideal for use in environments where durability, ease of use, and reliability are paramount.
Technical Specifications of PP885 Touch Display
- Model: PP885 3BSE069276R1
- Display Size: 15.4 inches
- Resolution: 1280 × 800 pixels (TFT-LCD)
- Brightness: 450 cd/m²
- Viewing Angle: Horizontal: 160°, Vertical: 140°
- Touch Screen Type: Polyester on glass, resistive (Autoflex EBA 180L)
- Touch Operations: 1 million finger touches
- Front Panel Seal: IP65
- Rear Panel Seal: IP20
- Mounting Depth: 76 mm (176 mm including clearance)
- Weight: 3.85 kg
- Processor: Intel® Atom
- Memory: 1 GB RAM (DDR2)
- Flash Memory (Application): 2 GB SSD (NAND Flash)
- External Storage: 1 × SD card (optional, up to 2 GB, compatible with standard SD format)
- Ethernet: 1 × 10/100/1000 Base-T (shielded RJ45)
- USB: 3 × USB 2.0 Host (Max 500 mA output current)
- Power Supply: +24 V DC (18-32 V DC), 24 W power consumption
- Fuse Rating: 3.15 A Slow
- Battery: Lithium battery (BR 2032 or CR 2032)
- Operating Temperature: -10°C to +50°C
- Storage Temperature: -20°C to +70°C
- Relative Humidity (in operation): 5% – 85% (non-condensing)
- Real-Time Clock: Yes (on-chip)
Frequently Asked Questions (FAQ)
Q: What is the maximum screw length for VESA mounting? A: The maximum screw length for VESA mounting is 4 mm. Using longer screws may damage the display.
Q: Can I use the PP885 in outdoor environments? A: The PP885 has an IP65 rating on the front panel, making it suitable for outdoor use in environments where water and dust resistance are needed.
Q: Does the PP885 support SD card storage? A: Yes, the PP885 supports external SD cards (up to 2 GB), but only those in the standard SD format.
Q: What is the recommended operating temperature for the PP885? A: The recommended operating temperature range is -10°C to +50°C.
Q: How many touch operations can the PP885 handle? A: The PP885 can handle up to 1 million finger touch operations.
For more detailed information, please check official datasheet: Panel 800 Version 6 PP885
