ABB Bailey SPASI23 Analog Input Module

Overview:

The ABB Bailey SPASI23 is a high-performance Analog Input Module designed for a variety of industrial applications. With 16 channels, it supports Thermocouple (TC), Millivolt (mV), and Resistance Temperature Detector (RTD) signals. This versatile module offers accurate signal conversion for precise measurements in demanding environments.

Technical Specifications:

• Brand: ABB
• Model: SPASI23
• Dimensions:
  • Depth: 73.66 mm
  • Height: 360.68 mm
  • Width: 269.24 mm
• Weight: 0.771 kg
• Number of Input Channels: 16
• Input Types Supported: TC, mV, RTD, High-Level
• Supported Signal Types:
  • Thermocouple (TC)
  • Millivolt (mV)
  • Resistance Temperature Detector (RTD)
• Environmental Rating: WEEE Category 5 (Small Equipment, No External Dimension Exceeding 50 cm)
• Battery Requirements: None
• Installation Components: Cable and terminal board included

FAQ:

1. What are the input types supported by the SPASI23 module?
   The SPASI23 supports Thermocouple (TC), Millivolt (mV), and RTD signals.
2. Can this module be used with ABB DCS systems?
   Yes, it is fully compatible with ABB’s distributed control systems (DCS) for real-time process monitoring.
3. What is the weight of the SPASI23 module?
   The module weighs 0.771 kg, making it lightweight and easy to install.
4. What are the installation requirements?
   The module comes with a cable and terminal board for seamless installation.
