ABB SB822 | Rechargeable Battery Unit 3BSE018172R1

Overview:

The ABB Rechargeable Battery Unit (Article number: SB822 3BSE018172R1) is designed for use with AC 800M controllers, providing a reliable power backup solution. This external DIN-rail mounted unit offers simple installation and optimal performance in demanding environments. Featuring a lithium-ion battery and 24V DC connector, it ensures your AC 800M controller remains operational during power interruptions.

Technical Specifications:

• Brand: ABB
• Model: AC 800M Rechargeable Battery Unit
• Article Number: SB822 3BSE018172R1
• Rated Output Voltage: 3.6 V
• Maximum Output Current: 0.05 A
• Width: 85.8 mm (3.38 inches)
• Depth: 58.5 mm (2.3 inches)
• Height: 136 mm (5.35 inches, including hatch)
• Weight: 550 g (1.21 lbs.)
• Maximum Ambient Temperature: 60 °C
• Equivalent Lithium Metal: 0.8 g (0.03 oz)
• Protection Rating: IP20 (IEC 60529)
• Pollution Degree: 2 (IEC 60664-1)
• Corrosive Atmosphere: G2 (ISA-S71.04)
• Mechanical Operating Conditions: IEC 61131-2
• RoHS Compliance: DIRECTIVE/2011/65/EU
• WEEE Compliance: DIRECTIVE/2012/19/EU

FAQ:

1. What is the main use of this rechargeable battery unit?
   • It provides backup power to the ABB AC 800M controllers, ensuring continuous operation during power failures.
2. What is the protection rating of the unit?
   • The unit has an IP20 protection rating, providing protection against solid objects larger than 12 mm but not against liquids.
3. How do I install the unit?
   • The unit can be easily mounted on a DIN rail for secure installation in control panels.
4. What is the weight of the unit?
   • The unit weighs 550 g (1.21 lbs.).
5. Is the unit RoHS compliant?
   • Yes, it is RoHS compliant under Directive 2011/65/EU.

For more detailed information, please check official datasheet: S800_I_O_Modules_and_Termination_Units
