ABB SPDSI14 Digital Input Module Bailey Infi 90 and Net 90

Overview

The ABB SPDSI14 Digital Input Module, part of the Bailey Infi 90 and Net 90 systems, offers efficient control with 16 input channels. This module is designed for industrial environments requiring robust digital input functionality. It is ideal for use in automation systems where reliable signal transmission is essential.

Technical Specifications

• Product ID: SPDSI14
• Catalog Description: DI Module, 16 Channels, 48 VDC (No Jumpers)
• Channel Type: Digital Input (DI)
• Number of Channels: 16
• Dimensions:
  • Length: 73.66 mm
  • Height: 358.14 mm
  • Width: 266.7 mm
• Weight: 0.2 kg
• Environmental: WEEE Category 5 (Small Equipment)
• No Batteries: This module requires no external power source other than the 48 VDC input.
• Jumpers: None
• Application: Used for integrating digital signals into process control systems. Suitable for industrial control applications requiring real-time monitoring of on/off states.

FAQ

1. What is the voltage requirement for the SPDSI14 module?
   The SPDSI14 module operates with a 48 VDC input voltage.
2. What is the number of channels provided?
   The module offers 16 digital input channels for signal processing.
3. Does the module require external power or batteries?
   No, this module operates solely on the 48 VDC input and does not require external batteries.
