ABB UR450 Mod. 5002 UV Flame Scanner

Overview

The ABB UR450 Mod. 5002 UV Flame Scanner is a high-performance flame detection device designed for industrial applications requiring reliable flame monitoring. With robust construction and advanced UV sensor technology, it ensures optimal performance in challenging environments.

Features

• High-sensitivity UV sensor with spectrum sensitivity of 190–280 nm.
• Durable IP66 (NEMA 4X) enclosure for harsh environments.
• Certified for use in explosive atmospheres (EEx-d IIC T6, ATEX category G-D).
• Compact dimensions of 165 x 126 x 126 mm and a weight of 2.5 kg.
• Compatible with ABB Uvisor MFD series amplifiers.
• CE-certified with ongoing approvals for FM and CSA standards.

Technical Specifications

• Brand: ABB
• Model: UR450 Mod. 5002
• Sensor Technology: High-sensitive UV sensor.
• Spectrum Sensitivity: 190–280 nm.
• Power Consumption: 800 mW, supplied by Uvisor MFD control units.
• Temperature Range: Operating: -10 to 100°C (14 to 212°F); Storage: -40 to 100°C (-40 to 212°F).
• Ambient Classifications: T6 areas (up to 60°C).
• Enclosure Rating: IP66 (NEMA 4X).
• Certifications: CE, ATEX (CESI 03 ATEX 151), FM and CSA (in progress).
• Lens Cleaning Requirements: Clean ambient air, minimum 20 mm H2O pressure above maximum wind box pressure; flow rates range from 115 l/min (4 SCFM) to 400 l/min (14 SCFM).
• Electrical Connections: Shielded cable (4 x 0.55 sq.mm), screw-type termination, up to 300 meters length.
• Mounting Type: Flanged.
• Cable Entry: 3/4″ NPT female thread.

FAQ

Q1: What is the detection range of the UR450 Mod. 5002 UV Flame Scanner?
A1: It detects UV flames within the spectrum sensitivity of 190–280 nm.

Q2: Can it be used in explosive environments?
A2: Yes, it is certified for explosive atmospheres (EEx-d IIC T6, ATEX).

Q3: What air pressure is needed for lens cleaning?
A3: Minimum 20 mm H2O above the maximum wind box pressure is required.

Q4: Is the scanner compatible with other amplifiers?
A4: It is designed to work specifically with ABB Uvisor MFD series amplifiers.

Check official datasheet for more detailed information:UR450 Data Sheet EC-DOC-G009DS002-A
