ABB XM06B5 XM-06-B5 Extension Input/output Module

Overview

The ABB XM-06-B5 Analog Extension Module offers robust functionality with 4 configurable analog inputs and 2 configurable analog outputs. Designed for precision and flexibility, it supports multiple signal types, making it suitable for various automation applications.

Features

• Versatile Inputs: Supports current, voltage, Pt100, Pt1000, NI1000, and Balco500 sensor types.
• High Compatibility: Seamlessly integrates with the AC31 PLC Series 40/50.
• Flexible Outputs: Configurable for both current and voltage signals.
• Compact Design: Dimensions (HxWxD): 93 x 65 x 85 mm, perfect for DIN rail mounting (IEC 60715 compliant).
• Environmental Tolerance: Operates between 0°C to +55°C; storage from -40°C to +75°C.
• Durable Construction: Certified by DNV, GL, and LR for industrial use.

Technical Specifications

• Brand: ABB
• Model: XM06B5/XM-06-B5 1SBP260103R1001
• Inputs: 4 analog, configurable
• Outputs: 2 analog, configurable
• Resolution: 12 bits
• Power Supply: External 24 V DC
• Operating Altitude: Up to 2000 meters
• Weight: 0.19 kg
• Protection Standards: CE certified with DNV, GL, and LR approvals.

FAQs

Q1: What signal types can the inputs process?
The inputs can handle current, voltage, and temperature signals (Pt100, Pt1000, NI1000, and Balco500).

Q2: Is it compatible with other PLCs?
This module is specifically designed for the ABB AC31 PLC Series 40/50.

Q3: What is the maximum operating altitude?
The module is rated for use up to 2000 meters.

Q4: How is it mounted?
The XM06B5 can be mounted on a DIN rail (TH35-15 or TH35-7.5) compliant with IEC 60715 standards.

For more detailed information, please check official datasheet: Advant Controller 31
