ABB XO16N1 XO-16-N1 Extension Module

Overview

The ABB XO-16-N1 (1SBP260105R1001) is a high-performance digital output module designed for industrial automation applications. With 16 transistor outputs at 24 V DC and 0.5 A per channel, it ensures reliable control and seamless integration into ABB’s AC31 Series 40/50 PLC systems.

Features

• Compact Design: Fits conveniently on TH35 DIN rails as per IEC 60715 standards.
• Robust Performance: Operates reliably within 0 to +55°C and can be stored from -40 to +75°C.
• Certification: DNV (DNV_A-8389), GL (GL_17 179-00 HH), LR (LR_00-20009-E1), and CE compliant.
• Durability: Supports maximum operating altitudes up to 2000 meters.
• Efficient Power: Requires an external 24 V DC power supply for operation.

Technical Specifications

• Brand: ABB
• Model: XO16N1/XO-16-N1
• Product ID: 1SBP260105R1001
• Outputs: 16 transistor outputs, 24 V DC, 0.5 A
• Dimensions: 85 mm (depth) x 65 mm (width) x 93 mm (height)
• Weight: 0.22 kg
• Mounting: Compatible with TH35-7.5 or TH35-15 DIN rails
• Operating Temperature: 0 … +55°C
• Storage Temperature: -40 … +75°C
• Certifications: DNV, GL, LR, CE

FAQ

1. What does the module control?
The XO16N1 is used to control digital outputs like solenoids, relays, and LEDs in automated systems.

2. Is it suitable for high-altitude applications?
Yes, it can operate at altitudes up to 2000 meters.

3. Can it be mounted on any DIN rail?
The module is compatible with TH35-15 and TH35-7.5 rails as per IEC 60715 standards.

4. What is the maximum output current per channel?
Each output can handle up to 0.5 A.

For more detailed information, please check official datasheet: Advant Controller 31
