ACS880-01-025A-3 ABB 11kW AC Drive

Overview

The ABB ACS880-01-025A-3 is a high-performance low-voltage frequency converter tailored for industrial applications across a variety of sectors, including mining, oil and gas, automotive, food and beverage, water and wastewater, power plants, and material handling. Designed to meet diverse application needs, this wall-mounted single drive offers reliable performance and advanced features, all in a compact package.

Technical Specifications

• Brand: ABB
• Model: ACS880-01-025A-3
• Nominal Power Output: 11 kW (15 HP)
• Input Voltage: 380-415 V (3-phase)
• Output Current (In): 25 A
• Efficiency Class: IE2
• Frequency Range: 47.5 to 63 Hz
• Temperature Rating: Up to 40°C operational
• Enclosure Protection: IP21, NEMA Type 1
• Analog Inputs/Outputs: 2 each
• Digital Inputs/Outputs: 6 / 2
• Communication Protocol: PROFINET IO, USB, RS-485

FAQs

1. What is the enclosure rating of the ACS880-01-025A-3?
   The standard enclosure is rated at IP21, with optional configurations available for IP55.
2. Can the ACS880-01 be installed in a cabinet?
   Yes, the drive is suitable for wall-mounted or cabinet installation.
3. What is the noise level during operation?
   The sound pressure level is 59 dB(A).
4. Does this model support functional safety?
   Yes, functional safety options are available for enhanced operational safety.
5. Is it compatible with PROFINET communication protocols?
   Yes, the drive supports PROFINET IO, ensuring seamless integration.

For more detailed information, please check official datasheet: 3AUA0000107992
