ACS880-01-206A-3 ABB Variable Frequency Drive

Overview

The ACS880-01-206A-3 is a highly versatile and compact industrial AC drive designed by ABB for demanding applications. It is ideal for various industries including oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. With a power output of 110 kW and 206 A current rating, it effectively controls motors in applications such as cranes, conveyors, mixers, compressors, pumps, and more.

Key Features and Applications:

• Brand: ABB
• Model: ACS880-01-206A-3
• Power Output (Pn): 110 kW
• Current Rating (In): 206 A
• Input Voltage: 380 to 415 V
• Protection Class: IP21
• Altitude Limit: 4000 m
• Operating Temperature: Max 40°C
• Communication Protocol: PROFINET IO
• Mounting Type: Wall-mounted (standard), cabinet (optional)
• Applications: Ideal for controlling motors in cranes, extruders, winches, conveyors, compressors, centrifuges, mixers, test benches, elevators, and more.

Technical Specifications:

• Frequency Range: 47.5 – 63 Hz
• Frame Size: R7
• Enclosure Type: NEMA Type 1
• Efficiency: IE2
• Apparent Power Output: 143 kV·A
• Sound Level: 67 dB(A)
• Analog Inputs: 2
• Analog Outputs: 2
• Digital Inputs/Outputs: 6 / 2
• Battery Information: 2 x Lithium Coin, CR2032, 220 mAh
• Standby Loss: 42 W

Performance Efficiency:

• Efficiency at Full Load: 94.1%
• Efficiency at 50% Load: 96.5%
• Efficiency at 25% Load: 95.6%
• Operating Point Efficiency:
  • 0 / 100%: 94.1%
  • 50 / 50%: 96.5%
  • 90 / 50%: 97.7%

Ordering Information:

• Product ID: 3AUA0000108028
• Customs Tariff Number: 85044086
• HS Code: 850440 – Static converters
• Country of Origin: Finland
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece

Frequently Asked Questions (FAQ):

1. What industries use the 3AUA0000108028?
2. The 3AUA0000108028 is commonly used in industries like mining, metals, cement, chemical processing, and food and beverage, among others.
3. What is the input voltage range of the 3AUA0000108028?
4. It operates within the input voltage range of 380 to 415 V.
5. How do I mount the 3AUA0000108028?
6. The drive is designed to be wall-mounted by default, but it can also be installed in a cabinet as an option.
7. What kind of protection does the drive offer?
8. The drive has an IP21 protection rating, ensuring reliability in industrial environments. It is suitable for installations up to 4000 meters altitude.
9. What is the power output of the 3AUA0000108028?
10. The drive provides an output power of 110 kW, which is suitable for a wide range of industrial applications.

For more detailed information, please check official datasheet: 3AUA0000108028
