ACS880-01-430A-3 ABB VFD 270HP 363A 400V

Technical Specifications:

• Brand: ABB
• Model: ACS880-01-430A-3
• Power Output: 250 kW (normal use), 200 kW (light overload), 200 kW (heavy-duty use)
• Input Voltage: 380 … 415 V
• Output Current: 430 A (normal use), 400 A (light overload), 363 A (heavy-duty use)
• Sound Level: 70 dB(A)
• Frame Size: R9
• Efficiency Level: IE2
• Degree of Protection: IP21 (standard)
• Temperature Rating: Max 40°C, Min -15°C
• Mounting Type: Wall-mounted
• Communication Protocol: PROFINET IO
• Standby Loss: 83 W
• Dimensions: 16.26″ (W) x 37.60″ (H) x 14.96″ (D)
• Net Weight: 209.44 lbs
• Customs Tariff Number: 85044086

Applications: The ACS880-01-430A-3 frequency converter is widely used in various industrial applications including but not limited to:

• Cranes
• Extruders
• Winches
• Compressors
• Mixers
• Elevators
• Pumps
• Fans

FAQ:

1. What industries is the 3AUA0000108038 suitable for?
   • The ACS880-01 is designed for industries such as oil & gas, mining, automotive, chemicals, cement, power plants, and food & beverage.
2. What is the power output of the 3AUA0000108038?
   • The power output is 250 kW under normal conditions and 200 kW under light overload and heavy-duty use.
3. How efficient is the 3AUA0000108038?
   • The drive boasts efficiency levels of up to 97.8%, depending on the operating point.
4. What are the mounting options for this drive?
   • The ACS880-01 can be mounted on the wall as standard, or optionally installed in a cabinet.
5. What communication protocols are supported?
   • The drive supports PROFINET IO, RS-485, and USB interfaces.

For more detailed information, please check official datasheet: 3AUA0000108038
