Product details
Overview
The AI-Tek Instruments 70084-1713-111 speed sensor, designed for demanding environments, features robust construction and precise sensing capabilities. Its high temperature tolerance and reliable output make it ideal for industrial applications.
Technical Specifications
- Brand & Model: AI-Tek Instruments, 70084-1713-111
- Output Voltage (Standard): 190 V (P-P)
- Output Voltage (Guarantee Point): 13.9 V (P-P)
- DC Resistance: 1200 ohms maximum
- Inductance: 400 mH (reference value)
- Output Polarity: Pin ‘B’ delivers a positive signal
- Operating Temperature Range: -40°C to +150°C
- Thread Size: 5/8-18
- Thread Length (A): 1.125 inches (28.57 mm)
- Sensor Length: 2.5 inches
- Termination: Connector type
- Net Weight: 2 oz (maximum)
- Suffix Meaning: “111” refers to specific thread size and configuration.
- Agency Approvals: Meets industrial quality standards.
Applications
- Industrial machinery speed monitoring
- Automotive testing and diagnostics
- Aerospace and defense systems
- Automation control systems
Frequently Asked Questions (FAQ)
- What is the primary application of the 70084-1713-111 sensor?
It is widely used in speed measurement tasks across industries, such as machinery monitoring and automation control. - What does the model suffix ‘111’ signify?
The suffix denotes a specific configuration, including thread size, length, and connector type. - Is the sensor compatible with extreme temperatures?
Yes, the operating temperature range of -40°C to +150°C ensures its performance in harsh environments. - What is the typical output voltage of the sensor?
The sensor delivers a standard output voltage of 190 V (P-P), ensuring reliable performance. - How is the sensor connected to external systems?
A connector-based termination allows for secure and efficient integration.
For more detailed information, please check official datasheet: Passive-Sensor_UL-ATEX-CSA
