Allen-Bradley 1769-L32E CompactLogix 750KB Enet Controller

Overview

The Allen-Bradley 1769-L32E is a powerful and compact programmable automation controller (PAC) from Rockwell Automation’s CompactLogix 5370 family. This versatile controller is ideal for medium-sized process and machine control applications. With built-in Ethernet and RS232 communication ports, the 1769-L32E supports seamless connectivity for enhanced control. The system features 750 KB of embedded memory, with an option for expansion via a CompactFlash card.

Technical Specifications

• Manufacturer: Rockwell Automation / Allen-Bradley
• Brand: Allen-Bradley
• Model: 1769-L32E
• Series: 5370 CompactLogix
• Product Type: Programmable Automation Controller (PAC)
• Module Type: Processor Module
• Communication Ports: 1 RS232, 1 Ethernet
• Supported Protocols: EtherNet/IP, DH485, DF1, ASCII
• Memory: 750 KB
• Maximum I/O Modules Supported: 16 Modules
• Maximum I/O Banks Supported: 3 Banks
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Shipping Weight: 2 lbs
• Shipping Dimensions: 8 x 8 x 5 inches
• Battery: 1769-BA
• Programming Cable: 1747-CP3 / 1756-CP3
• Power Supply: 5V DC (850mA)
• Vibration: 5G Operating, 10 to 500 Hz

Ordering Information

• Part Number: 1769-L32E
• Accessories:
  • 1769-BA (Battery)
  • 1784-CF64, 1784-CF128 (CompactFlash Cards)
  • 1747-CP3, 1756-CP3 (Programming Cables)

Check official datasheet for more detailed information: 1769 CompactLogix Controllers
