Allen-Bradley 22F-A2P5N103 Frequency AC Drive

Overview

The Allen-Bradley PowerFlex 527 Adjustable Frequency AC Drive (Model: 22F-A2P5N103) is a compact and efficient drive designed for reliable motor control in various industrial applications. With an input voltage of 200-240 VAC and an output of 0-230 VAC, it offers excellent performance for 1-phase input to 3-phase output conversion. The drive is ideal for situations that require compact size, easy integration, and basic control functionality.

Features

• Input Voltage: 200-240 VAC, 1-Phase
• Output Voltage: 0-230 VAC, 3-Phase
• Control Method: V/Hz control
• Enclosure Type: IP20, Open
• Communication: RS485
• Human Interface Module: Built-in standard keypad
• Discrete Inputs: 5 x 24 VDC discrete inputs
• Analog Inputs: 2 analog inputs
• Discrete Outputs: 2 Form C relay outputs
• Braking: No IGBT brake installed
• EMC Filter: None installed
• Frame Size: A
• Output Power: 0.5 HP (0.37 kW)
• Output Current: 2.5 A
• Input Current: 2.7 A

Technical Specifications

• Brand: Allen-Bradley
• Model: 22F-A2P5N103
• Powerflex Line: PowerFlex 4M
• Amperage: 2.5 Amperes
• Output Power: 0.5 HP / 0.37 kW
• Input Power: 200-240 VAC, 1-Phase
• Output Voltage: 0-230 VAC, 3-Phase
• Horsepower Rating: 0.5 HP / 0.37 kW
• Frame Type: A
• Control Method: V/Hz
• Communication Ports: RS485
• Enclosure: IP20 NEMA/Open

FAQ

1. What is the output voltage for the 22F-A2P5N103?
   The output voltage is 0-230 VAC, 3-phase.
2. What type of communication does the drive support?
   It supports RS485 communication for easy integration with control systems.
3. Does this drive have an EMC filter installed?
   No, the EMC filter is not installed on this model.
4. Can this drive be used for 3-phase input?
   No, this drive is designed for 1-phase input to 3-phase output.

Check official datasheet for more detailed information: PowerFlex 4M Adjustable Frequency AC Drive
