Allen-Bradley 22F-B033N104 AC Drive 7.5 kW 10 HP

Overview

The Allen-Bradley 22F-B033N104 is part of the PowerFlex 4M series by Rockwell Automation. Designed for efficient motor control, this drive is ideal for applications requiring precise performance in a compact, open-frame design. With a 10 HP output and a 7.5 kW power rating, it is engineered to handle demanding industrial operations.

Features

• Compact Frame: Frame Size C for space-efficient installation.
• Open Enclosure: IP20-rated, suitable for controlled environments.
• RS-485 Communication: Integrated port for seamless communication and control.
• Digital Control Interface: Fixed keypad with an LED display for easy operation.
• Voltage Flexibility: Operates on 208-240V AC input for diverse applications.
• High Current Capacity: Supports up to 33 Amps output.
• No CE Filter: Designed without a CE-compliant filter for specific requirements.

Technical Specifications

• Brand/Manufacturer: Allen-Bradley, Rockwell Automation
• Model: 22F-B033N104 (Suffix Explanation: “22F” denotes PowerFlex series; “B033” indicates 33 Amps output; “N104” specifies no CE filter)
• Power Ratings: 7.5 kW (10 HP)
• Input Voltage Range: 200-240V AC, 3-phase
• Output Voltage Range: 0-230V AC, 3-phase
• Enclosure Type: Open, IP20
• Amperage: 33 Amps
• Communication Port: RS-485
• Frequency Range: 0 to 400 Hz

FAQs

1. What does the suffix “N104” signify in 22F-B033N104?
It indicates the absence of a CE-compliant filter in this model.

2. Can this drive operate with a single-phase input?
No, it is specifically designed for 3-phase input systems.

3. What kind of communication is supported?
The drive features an RS-485 port for communication.

4. Is it suitable for outdoor use?
No, the IP20 rating limits its application to controlled indoor environments.

5. How do I monitor performance?
The fixed keypad and LED display provide straightforward operational feedback.

Check official datasheet for more detailed information: PowerFlex 4M Adjustable Frequency AC Drive
