Allen-Bradley 22F-D1P5N113 Adjustable Frequency AC Drive

Overview

The Allen-Bradley 22F-D1P5N113 PowerFlex 4M is a robust and versatile adjustable frequency drive from Rockwell Automation. Designed for industrial motor control applications, it offers seamless operation with advanced communication capabilities, making it a reliable choice for various environments.

Features

1. Compact Design: Open-type IP20 enclosure for efficient cooling and easy integration into control panels.
2. Advanced Communication: Built-in RS-485 port for streamlined connectivity with industrial networks.
3. CE-Compliant Filter: Ensures reduced electrical noise for compliance with international standards.
4. Wide Input Voltage Range: Operates on a 3-phase input of 380-480V AC with output up to 460V AC.
5. Temperature Resilience: Performs optimally between 14°F and 122°F (-10°C to 50°C) with up to 95% relative humidity (non-condensing).

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 22F-D1P5N113
  • 22F: PowerFlex 4M series designation
  • D1P5: 1.5 Amps rating
  • N: With CE-compliant filter
  • 113: Voltage and enclosure configuration identifier
• Input Power: 380-480V AC, 3-phase
• Output Voltage: 0-460V AC, 3-phase
• Amperage: 1.5 Amps
• Power Rating: 0.4 kW (0.5 HP)
• Enclosure Type: Open-IP20
• Compliance: CE-certified for noise filtration

Applications

• Industrial motor control and automation systems.
• Conveyor systems, pumps, and fans in manufacturing plants.
• Compact control solutions for HVAC systems.
• Packaging machinery requiring precise speed control.

FAQ

Q1: Is the 22F-D1P5N113 suitable for outdoor use?
A: No, its IP20 rating is intended for indoor, controlled environments.

Q2: Can this drive handle single-phase input?
A: No, the 22F-D1P5N113 requires 3-phase input power for operation.

Q3: Does it support fieldbus communication?
A: Yes, it comes with an RS-485 port for network communication.

Q4: Can it operate in extreme humidity?
A: Yes, it is rated for up to 95% relative humidity, non-condensing.

Check official datasheet for more detailed information: PowerFlex 4M Adjustable Frequency AC Drive
