Allen-Bradley | 22F-V1P6N103 | Adjustable Frequency AC Drive

Overview:

The Allen-Bradley 22F-V1P6N103 is a compact and reliable PowerFlex 4M adjustable frequency AC drive, designed for precise motor control in a variety of applications. It offers efficient speed control and energy savings for 1-phase systems, with a wide input voltage range and a robust set of features suitable for both industrial and commercial use.

Key Features:

• Input Voltage: 100-120VAC, 1-phase
• Output Voltage: 0-460VAC, 3-phase
• Output Power: 0.2 kW (0.25 HP)
• Output Current: 1.6 A
• I/O: 5 Discrete Inputs (Sink/Source), 1 Discrete Output (Form C Contacts), 1 Analog Input (0-10VDC; 0-20mA)
• Control Method: Volts/Hertz
• Communication: RS485 built-in, optional BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, ControlNet protocols
• Enclosure Rating: IP20 / NEMA Open Type
• Panel Mount Installation

Technical Specifications:

• Brand: Allen-Bradley
• Model: 22F-V1P6N103
• Input Voltage: 100-120VAC
• Input Current: 6.4 A
• Output Voltage: 0-460VAC
• Output Phase: 3-Phase
• Output Current: 1.6 A
• Power Output: 0.2 kW (0.25 HP)
• Amperage: 1.6 A
• Enclosure: IP20 / NEMA Open Type
• Phase: 1-Phase input
• Frame Size: A
• Control Performance: Volts / Hertz
• Installation: Panel Mount
• Optional Communication Protocols: BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, ControlNet

FAQ:

1. What is the voltage range of the Allen-Bradley 22F-V1P6N103?
   The drive operates within an input voltage range of 100-120VAC and can deliver an output voltage of 0-460VAC.
2. What is the maximum output current?
   The maximum output current is 1.6 A.
3. What types of communication protocols are supported?
   It supports RS485 communication, with optional protocols such as BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, and ControlNet.
4. Is this drive UL certified?
   Yes, it has UL and NEMA Open Type certifications, making it suitable for various industrial applications.
5. What are the mounting options?
   This drive is designed for panel mounting.

Check official datasheet for more detailed information: PowerFlex 4M Adjustable Frequency AC Drive
