Allen-Bradley | 22F-V2P5N103 | 120VAC, 1PH AC Drive

Overview

The Allen-Bradley 22F-V2P5N103 PowerFlex 4M is a versatile and efficient adjustable frequency AC drive designed for panel mounting in industrial applications. With an input voltage of 100-120VAC and a 1-phase configuration, it delivers a 0-230VAC output voltage at 2.5A with a power rating of 0.4 kW (0.5 HP). The drive supports multiple communication protocols, including RS485 for easy integration into various control systems.

Key Features:

• Input Voltage: 100-120 VAC, 1-phase, 50-60Hz
• Output Voltage: 0-230VAC, 3-phase
• Power Rating: 0.4 kW (0.5 HP)
• Current Rating: Output current of 2.5A
• Control Method: Volts/Hertz Control
• Communication: Built-in RS485, optional BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, ControlNet
• Enclosure Type: IP20 / UL NEMA Open Type, Panel Mount
• I/O: 5 discrete inputs, 1 discrete output (Form C contacts), 1 analog input (0-10VDC, 0-20mA)
• Installation: Designed for panel mounting

Technical Specifications:

• Manufacturer: Rockwell Automation
• Model: 22F-V2P5N103 (PowerFlex 4M Series)
• Brand: Allen-Bradley
• Input Power: 120V AC, 1-phase, 9.0A
• Output Power: 0.4 kW (0.5 HP), 2.5A output current
• Enclosure Rating: IP20 / NEMA Type Open
• Optional Communication Protocols: BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, ControlNet

Applications:

The 22F-V2P5N103 PowerFlex 4M is ideal for controlling motor speeds in HVAC systems, pumps, fans, and conveyor belts, as well as for various general-purpose industrial applications. Its compact design and flexibility make it a popular choice in both OEM and retrofit installations.

FAQ:

1. What is the input voltage range for this drive?
   • The input voltage range is 100-120VAC, 1-phase, supporting 50-60Hz.
2. Can the PowerFlex 4M be used in outdoor environments?
   • The drive is rated IP20, meaning it should be installed in indoor environments or enclosures with sufficient protection.
3. What communication protocols does the drive support?
   • It supports RS485, with options for BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, and ControlNet.
4. What is the mounting type for this drive?
   • This drive is designed for panel mounting.
5. What is the drive’s output current and power?
   • The output current is 2.5A, with a power rating of 0.4 kW (0.5 HP).

Check official datasheet for more detailed information: PowerFlex 4M Adjustable Frequency AC Drive
