Allen-Bradley 25A-E9P9N104 PowerFlex 523 AC Drive 3 Phase

Overview

The Allen-Bradley PowerFlex 523 AC Drive (model 25A-E9P9N104) is a high-performance drive designed for demanding industrial applications. Supporting both Normal Duty and Heavy Duty operations, this compact drive delivers reliable control for various motor types in a user-friendly package.

Features

• Flexible Power Options: Supports 7.5 HP (5.5 kW) for Normal and Heavy Duty applications.
• Voltage Compatibility: Operates at 600 VAC, 3-phase input, ensuring adaptability to diverse setups.
• Compact Frame Design: Frame C design with IP20 NEMA/Open Type enclosure for easy integration.
• Customizable Control: No integrated filter, allowing users to add external filters as needed.
• Efficient Motor Control: Delivers precise and efficient motor operation, reducing energy consumption.

Technical Specifications

• Brand: Allen-Bradley
• Model: 25A-E9P9N104
• Voltage Input: 600 VAC, 3-phase
• Output Current: 9.9 Amps
• Power Capacity:
  • Normal Duty: 7.5 HP (5.5 kW)
  • Heavy Duty: 7.5 HP (5.5 kW)
• Frame Size: Frame C
• Enclosure: IP20 NEMA/Open Type
• Suffix Breakdown:
  • “25A”: PowerFlex Series
  • “E9P9”: Indicates 9.9 Amps
  • “N104”: Designates No Filter

Applications

This AC drive is ideal for industries requiring precision motor control, including:

• Conveyor systems in manufacturing facilities.
• HVAC systems for energy-efficient operation.
• Water treatment plants for pump and fan management.
• Packaging equipment requiring adaptable motor speeds.

FAQ

Q1: Does the 25A-E9P9N104 include a built-in filter?
A1: No, this model does not include an integrated filter, allowing users to install external filters based on their requirements.

Q2: What enclosure rating does this drive have?
A2: It features an IP20 NEMA/Open Type enclosure, suitable for controlled environments.

Q3: Can it operate in both Normal and Heavy Duty conditions?
A3: Yes, it supports both Normal Duty (7.5 HP, 5.5 kW) and Heavy Duty (7.5 HP, 5.5 kW) operations.

Q4: What industries can benefit from this drive?
A4: Industries such as manufacturing, HVAC, water treatment, and packaging widely use this drive for motor control.

Check official datasheet for more detailed information: PowerFlex 520-series AC Drive
