Allen-Bradley 25A-V1P6N104 PowerFlex 523 AC Drive

Overview

The Allen-Bradley 25A-V1P6N104 PowerFlex 523 is a versatile AC drive offering compact design, reliable performance, and advanced motor control for applications requiring up to 0.25 HP (0.2 kW) output. Operating on a 120V AC single-phase input, it supports an output voltage range of 0-230V AC, making it suitable for various industrial and commercial settings.

Features

• Compact Frame A Design: Space-saving and easy to install in tight enclosures.
• Multi-Motor Control Modes: Volts/Hertz, Sensorless Vector Control (SVC), and Economizer SVC ensure precise and efficient motor performance.
• Advanced Protection: Class 10 motor overload protection, short-circuit trip, and overcurrent safeguards.
• Flexible Connectivity: Includes Ethernet/IP, RS485, and optional DeviceNet or PROFIBUS DP communication.
• Wide Frequency Range: Adjustable output frequency from 0 to 500 Hz for diverse motor applications.
• High Efficiency: Delivers 97.5% energy efficiency to minimize operational costs.

Technical Specifications

1. Brand: Allen-Bradley (Rockwell Automation)
2. Model: PowerFlex 523, Catalog No. 25A-V1P6N104
   • Suffix Breakdown:
     • 25A: PowerFlex 523 Series
     • V1P6: 1.6A Output Current
     • N104: No EMC Filter, Frame A, IP20 Enclosure
3. Input Voltage: 100-120V AC, single-phase
4. Output Voltage: 0-230V AC, 3-phase
5. Output Current: 1.6A
6. Control Modes: V/Hz ±1%, SVC ±0.5%, Economizer SVC
7. Communication: Embedded Ethernet/IP and RS485 ports
8. Carrier Frequency: 4 kHz (default), adjustable 2-16 kHz
9. Stop Modes: Ramp, Coast, DC-Brake, Ramp-to-Stop
10. Environmental Limits: -20°C to 50°C (-4°F to 122°F); up to 1000m altitude without de-rating

Applications

The PowerFlex 523 is ideal for applications such as conveyor belts, pumps, fans, and mixers, where compact size, precise motor control, and robust performance are essential. Its wide range of connectivity options ensures seamless integration into automation systems.

FAQ

1. What does the 25A-V1P6N104 model suffix mean?
The “25A” identifies the PowerFlex 523 series, “V1P6” specifies 1.6A output current, and “N104” denotes a Frame A design without EMC filtering.

2. Can this drive handle high altitudes?
Yes, it operates without performance de-rating at altitudes up to 1000m (3300 ft).

3. Does it include a cooling fan?
No, the drive’s heatsink does not come with a cooling fan, enhancing its compactness and reliability.

4. Is it suitable for harsh environments?
While it has IP20 open-type protection, additional enclosure measures are needed for harsh environments.

5. Can it be used for high-speed motor control?
Yes, the adjustable frequency range of up to 500 Hz supports high-speed motor applications.

Check official datasheet for more detailed information: PowerFlex 520-series AC Drive
