Allen-Bradley 2711P-RN15S Panel View Plus Module

Overview

The Allen-Bradley 2711P-RN15S is an advanced ControlNet communication module designed for PanelView Plus and PanelView Plus CE operator terminals. Offering reliable communication for industrial applications, this module facilitates efficient control and data exchange in networked environments. Compatible with PanelView Plus models (700 to 1500) and PanelView Plus CE models (700 to 1500), the 2711P-RN15S features two independent ControlNet communication channels, making it suitable for highly dynamic control systems.

Technical Specifications

• Brand: Allen-Bradley
• Part Number: 2711P-RN15S
• Model: PanelView Plus 700-1500
• ControlNet Ports: Two (2) ports (ChA and ChB)
• Network Access Port (NAP): One (1) RJ45 port
• ControlNet Media Compatibility: 1786-RG6/A and 1786-RG6F/B cables
• ControlNet Redundancy: Supported for higher availability
• Supported Nodes: 1 to 99 nodes for flexible configuration
• NAP Cable: 1786-CP cable
• Retaining Screw Size: M3 metric screw, 5 mm long
• Product Family: PanelView Plus / PanelView Plus CE Operator Terminals
• Application: Ideal for industrial automation and control systems, facilitating seamless communication between devices and operator terminals.

Dimensions & Weight

• Dimensions: 8.0″ x 5.0″ x 1.8″ (20.3 cm x 12.7 cm x 4.4 cm)
• Shipping Weight: 3 lbs (1.36 kg)
• Shipping Dimensions: 11″ x 8″ x 6″ (27.9 cm x 20.3 cm x 15.2 cm)

FAQ

1. What is the purpose of the 2711P-RN15S ControlNet module? The 2711P-RN15S serves as a communication interface between the PanelView Plus/PanelView Plus CE terminals and the ControlNet network, enabling efficient data exchange and control.
2. How many ControlNet channels does this module support? The module supports two ControlNet channels (ChA and ChB) for robust and flexible communication.
3. What is the meaning of “Redundancy Supported”? ControlNet redundancy ensures the reliability of the communication network. If one communication path fails, the system can automatically switch to the backup path, minimizing downtime.
4. Does this module support under-power insertion or removal? No, the module does not support insertion or removal under power, ensuring safe and secure installation.
5. What types of ControlNet cables are compatible with this module? The module is compatible with 1786-RG6/A and 1786-RG6F/B ControlNet cables.

For more detailed information, please check official datasheet:PanelView Plus ControlNet Communication Module
