Overview
The Allen-Bradley 22D-B5P0F104 PowerFlex 40P AC Drive is a versatile adjustable frequency drive, designed for precise control of three-phase induction motors. As part of the PowerFlex 40P series from Rockwell Automation, this cost-effective drive supports both open and closed-loop control. Its 1 HP (0.75 kW) output power and 240V AC input are ideal for various industrial applications. This unit features a flange-mount design, ensuring easy integration into a PLC system. The drive offers essential protection against environmental factors with an IP20 (NEMA Type 1 open) enclosure.
Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 22D-B5P0F104
- Series: PowerFlex 40P
- Input Voltage: 240V AC (Three-Phase)
- Amperage: 5 Amps
- Horsepower: 1 HP (0.75 kW)
- Frame Size: B
- Enclosure: Open NEMA Type (Flange Mount) – IP20
- Control Methods: Sinusoidal PWM, Volts per Hertz, Sensorless Vector Control
- Frequency Range: 0 to 500 Hz
- Protection Features: Ground fault, short-circuit, over/under voltage, overcurrent, and motor overload protection
- Communication: RS485 for PC programming
- Analog Inputs: 2, configurable for 0-10V DC or 4-20 mA
- Relay Output: Programmable 1NO/1NC relay (3A rated)
- Cooling Method: Convection cooling
- Operating Temperature: -10 to 50°C (14 to 122°F)
- Enclosure Dimensions: 145 x 210 x 119.3 mm (5.71 x 8.27 x 4.70 in)
FAQ
- What is the input voltage range?
- The input voltage range is from 180 to 264V AC (three-phase).
- Can this drive be used for open-loop control?
- Yes, it can be used for both open and closed-loop control.
- Is there a filter included with this drive?
- No, the 22D-B5P0F104 does not include a CE Compliant Filter.
- What is the cooling method for this drive?
- The drive uses convection cooling, ensuring efficient heat dissipation.
Check official datasheet for more detailed information: PowerFlex 40P
