Allen-Bradley SST-PFBCLX Module Profibus Scanner Module

Overview

The SST-PFBCLX PROFIBUS Interface Module (PBIM) is a CIOM-A form-factor, single-slot width module designed for robust industrial communication. Operating as a PROFIBUS DP Class 1 Master, it supports multi-master configurations and various baud rates, ensuring seamless integration in industrial environments. The module is ideal for applications involving Siemens Simatic® ET200M I/O, Simocode 3UF5 Motor Protection Units, and more.

Features

• Model: SST-PFBCLX
• Brand: SST
• Interface: PROFIBUS DP Class 1 Master
• Applications: Motor protection, weighing systems, industrial I/O, encoder systems
• Compatibility: Siemens devices, Bizerba Weighing Terminals
• Electrical Connection: Optically isolated 9-pin female connector
• Durability: Vibration resistant (10–50 Hz, 5 g) and shock resistant (30 g peak, 11 ms)

Technical Specifications

1. Physical Form-Factor: CIOM-A, single-slot width
2. Chassis Locations: Non-redundant controllers or remote I/O chassis
3. PROFIBUS Baud Rates: Ranges from 9.6 Kbps to 12 Mbps
4. Diagnostic Data: Configurable up to 244 bytes
5. Station Address Range: Valid between 0–125
6. Input Data Capacity: Up to 496 bytes (4–499 bytes valid range)
7. Output Data Capacity: Up to 492 bytes (4–495 bytes valid range)
8. Supported Profiles: PROFIDRIVE, Encoder
9. Data Types: Discrete, 8-bit/16-bit/32-bit integers, IEEE 32-bit floating-point
10. Supported Devices: Siemens Simatic ET200M, Simocode, Bizerba terminals

Applications

• Motor control and monitoring
• Industrial weighing systems
• Encoder integration
• Process automation

FAQ

Q: Does the SST-PFBCLX support redundancy?
A: No, the module does not support redundancy and is suited for non-redundant controllers or remote I/O chassis.

Q: What is the maximum number of modules supported?
A: The PBIM supports up to 100 modules per block, identified by unique station/module combinations.

Q: Can the baud rate be adjusted?
A: Yes, the PROFIBUS baud rate is configurable, ranging from 9.6 Kbps to 12 Mbps.

For more detailed information, please check official datasheet: C200-introduction
