Armored Extension Cable 330730-080-03-05 | Bently Nevada

Overview

The Bently Nevada 330730-080-03-05 3300 XL 11 mm Extension Cable is an essential component designed for precision measurements in challenging environments. Manufactured in the U.S.A., this extension cable boasts a number of options to cater to diverse application needs, ensuring reliability and durability. Its unique design allows it to maintain signal integrity even under extreme conditions, making it a vital tool for monitoring machinery effectively.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL
• Product Number: 330730-080-03-05
• Cable Length Option: 080 = 8.0 meters (26.2 feet)
• Connector and Cable Option: 03 Armored cable with connector protector
• Agency Approval Option: 05 Multiple Approvals
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Temperature Range: -51°C to +177°C (-60°F to +351°F)
• Armored Extension Cable Weight: 45 g/m (0.5 oz/ft), 0.36 kg
• Connector Material: Gold-plated brass
• Tensile Strength: 330 N (75 pounds) from probe case to probe lead
• Resistance Specifications: 2.0 ± 0.5 ohms for RCORE over 8 m and 0.6 ± 0.2 ohms for RJACKET

FAQ

• Q: What is the maximum cable length for this product?
  A: The maximum length is 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitor.
• Q: Can this cable be used outdoors?
  A: Yes, the robust design and optional connector protection make it suitable for outdoor use in various environmental conditions.
• Q: How does the cable maintain signal integrity?
  A: The construction using 75 Ω triaxial, fluoroethylene propylene (FEP) insulation helps maintain signal quality even in challenging environments.

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
