Armored Extension Cable Bently Nevada | 330730-040-01-05

Overview

The Bently Nevada 330730-040-01-05 3300 XL 11 mm Extension Cable is engineered for precision and reliability in industrial monitoring applications. Manufactured in the U.S.A., this extension cable features a length of 4.0 meters and is available with an armored option for enhanced durability. Notably, its FluidLoc version effectively prevents the leakage of oils and other liquids, making it ideal for robust operational environments.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 11 mm Extension Cable
• Product No.: 330730-040-01-05
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Operating Temperature Range: -51°C to +177°C (-60°F to +351°F)
• Resistance from Core Conductor (4.0 m): 1.0 ± 0.25 ohms
• Resistance from Jacket Conductor (4.0 m): 0.3 ± 0.1 ohms
• Tensile Strength: 330 N (75 lbs) probe case to probe lead
• Connector Material: Gold-plated brass
• Linear Range: 4.0 mm (160 mils) with recommended gap setting of 2.5 mm (100 mils)

Ordering Information

When ordering, please specify:

• Cable Length: 040 (4.0 meters)
• Connector Type: 01 (Armored cable)
• Agency Approval: 05 (Multiple approvals)

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
