Bently Nevada 177230-01-01-05 Seismic Transmitter

Overview

The Bently Nevada 177230-01-01-05 is a high-quality vibration sensor designed for velocity vibration measurement. With a rugged construction and IP65 protection rating, it is suitable for harsh industrial environments. This sensor provides a 4-20 mA output signal and operates within a wide temperature range of -40°C to 85°C. Its compact design, with multiple mounting options, ensures easy integration into existing systems.

Technical Specifications:

• Manufacturer: Bently Nevada
• Model Number: 177230-01-01-05
• Output Signal: 4-20 mA (current loop, velocity vibration)
• Power Supply: 12-30 VDC (current limited to 40 mA)
• Temperature Range: -40°C to 85°C
• Protection Rating: IP65
• Sensitivity (Main Loop):
  • 0.0 to 12.7 mm/s (0 to 0.5 in/s)
  • 0.0 to 25.4 mm/s (0 to 1.0 in/s)
  • 0.0 to 50.8 mm/s (0 to 2.0 in/s) ±10% FS (broadband RMS)
• Mounting Threads: M6 x 1 SI, M8 x 1.25 SI, ¼-28 UNF
• Case Material: 316L stainless steel
• Connector: 3-pin MIL-C-5015, stainless steel
• Dimensions:
  • Diameter: 25.4 mm (1.00 in)
  • Height: 66.0 mm (2.60 in)
• Weight: 131 g (4.62 oz)

FAQ:

1. What is the operating temperature range of the 177230-01-01-05 Seismic Transmitter?
   The device operates within a temperature range of -40°C to 85°C, making it suitable for extreme industrial environments.
2. What kind of protection does the seismic transmitter have?
   It is rated at IP65, providing protection against dust and water, ensuring its durability in harsh conditions.
3. What is the output signal of the transmitter?
   The transmitter provides a 4-20 mA output signal, which is ideal for integrating with a variety of monitoring systems.
4. Can this device be used with different monitoring systems?
   Yes, the seismic transmitter is compatible with various vibration monitoring systems, ensuring easy integration into your setup.

For more detailed information, please check official datasheet: 177230 Seismic Transmitter Datasheet
