Bently Nevada | 3300 NSv Extension Cable 330930-060-01-00

Overview

The Bently Nevada 330930-060-01-00 is a 3300 XL Standard Extension Cable designed for reliable connectivity in industrial applications. Compatible with Bently Nevada’s 3300 RAM and NSv series probes, it ensures precise signal transmission while offering enhanced chemical resistance and robust mechanical features.

Features

• Robust Build: Patented CableLoc design provides 220 N (50 lb) tensile strength for secure cable-to-probe connections.
• Enhanced Durability: Stainless steel armor with FEP jacket for excellent resistance to environmental stress.
• Superior Compatibility: Fully interchangeable with Bently Nevada’s 3300 RAM proximity probes.
• Advanced Protection: ClickLoc connectors prevent loosening; optional connector protectors safeguard against liquid ingress.
• Wide Temperature Range: Operates reliably between -52°C to +177°C (-62°F to +351°F).

Technical Specifications

• Brand: Bently Nevada
• Model: 330930-060-01-00
• Suffix Meaning:
  • 060: Cable length of 6.0 meters (19.7 feet).
  • 01: Stainless steel armor with FEP jacket.
  • 00: No agency approval required.
• Cable Material: 75 Ω coaxial, fluoroethylene propylene (FEP) insulated.
• System Length: 5 or 7 meters (including extension cable).
• Connector Material: Gold-plated brass for corrosion resistance.
• Armor Material: Flexible AISI 302 SST with optional FEP outer jacket.
• Applications: Suitable for process compressors and harsh industrial environments requiring precision monitoring.

Applications

The 3300 XL Standard Extension Cable is widely used in industrial machinery monitoring, including:

1. Process compressors.
2. High-vibration environments.
3. Chemical-resistant operations.
4. Applications needing reliable signal transmission in extreme temperatures.

FAQ

Q1: What is the tensile strength of the cable?
A: The cable has a tensile strength of 220 N (50 lb) at key connection points.

Q2: Can the cable withstand extreme temperatures?
A: Yes, it operates between -52°C to +177°C (-62°F to +351°F).

Q3: What does the 060 suffix in the model number signify?
A: It indicates a cable length of 6.0 meters (19.7 feet).

Q4: Is the cable compatible with previous Bently Nevada models?
A: Yes, it is mechanically and electrically compatible with 3300 RAM and NSv series probes.

Q5: Are connector protectors necessary?
A: While optional, connector protectors are highly recommended to prevent liquid ingress and ensure optimal signal transmission.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
