Bently Nevada | 3300 XL Extension Cable 330130-085-00-05

Overview

The Bently Nevada 3300 XL Standard Extension Cable (Part Number: 330130-085-00-05) delivers exceptional reliability for vibration monitoring systems. This cable is engineered with advanced CableLoc technology, ensuring a robust connection with a pull strength of 330 N (75 lbf). Designed for demanding environments, it offers options like FluidLoc, which prevents oil and fluid ingress. The cable is crafted with fluoroethylene propylene (FEP) insulation, providing durability and performance in industrial applications.

Key Features

• Model: 3300 XL Extension Cable
• Cable Length: 8.5 meters (27.9 feet)
• Connector Protector and Cable Option: 00 (Standard cable)
• Agency Approval: 05 (Multiple approvals)
• Material: 75-ohm triaxial, FEP insulated
• Weight: 0.89 kg

Technical Specifications

1. Power Requirements
   • Voltage: -17.5 Vdc to -26 Vdc
   • Consumption: 12 mA maximum
2. Cable Specifications
   • Capacitance: 69.9 pF/m (21.3 pF/ft) typical
   • Linear Range: 2 mm (80 mils), beginning at approximately 0.25 mm (10 mils) from the target
   • Field Wiring: Compatible with 16 to 24 AWG cables, up to 305 meters (1,000 feet)
3. Sensitivity & Resistance
   • Supply Sensitivity: <2 mV change per volt of input voltage variation
   • Output Resistance: 50 Ω
4. Environmental Parameters
   • Operating Temperature: +18˚C to +27˚C (+64˚F to +80˚F)
   • Max Altitude: 2000 meters

Additional Information on Suffix Options for 330130-085-00-05

• Model 330130: Indicates the standard extension cable series.
• 085: Refers to the cable length of 8.5 meters.
• 00: Specifies the use of a standard cable without additional protection.
• 05: Denotes multiple agency approvals, ensuring compliance with various industrial standards.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
