Bently Nevada 330104-03-07-05-02-05 3300 XL Proximity Probe

Overview:

The Bently Nevada 330104-03-07-05-02-05 is an advanced 8 mm proximity probe from the 3300 XL series, designed to offer reliable and precise monitoring of machinery vibration. Ideal for applications in harsh environments, it is used for machinery protection and condition monitoring in industries such as energy, manufacturing, and processing.

Technical Specifications

• Brand: Bently Nevada
• Model: 330104-03-07-05-02-05
• Type: 3300 XL 8 mm Proximity Probe
• Thread: M10 x 1 with armor
• Material:
  • Probe Tip: Polyphenylene sulfide (PPS)
  • Probe Case: AISI 303 or 304 stainless steel (SST)
• Power Requirements: -17.5 Vdc to -26 Vdc for nonincendive circuit connections. Operation at -23.5 Vdc or more positive may reduce linear range.
• Output Resistance: 50 Ω
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
• Approvals: CSA, ATEX, IECEx
• Weight: 0.7 Kg
• Length Options:
  • Unthreaded Length: 30 mm
  • Overall Case Length: 70 mm
  • Total Length: 0.5 meters (1.6 feet)
• Connector: Miniature coaxial ClickLoc™ connector
• Max Rated Torque: 33.9 N·m (300 in·lbf) for standard forward-mounted probes
• Recommended Torque: 11.2 N·m (100 in·lbf)

Frequently Asked Questions (FAQ)

Q1: What is the advantage of using the 8 mm probe design?
A1: The 8 mm probe design offers enhanced durability with thicker encapsulation, making it more resistant to physical damage and ideal for industrial environments where robustness is required.

Q2: What approvals does this proximity probe have?
A2: This probe has CSA, ATEX, and IECEx approvals, making it suitable for use in hazardous and explosive environments.

Q3: What is the power requirement for the probe?
A3: The probe requires -17.5 Vdc to -26 Vdc when installed with a nonincendive circuit, and it operates at a maximum current consumption of 12 mA.

Q4: Can I use this probe for applications in explosive atmospheres?
A4: Yes, the 3300 XL 8 mm Proximity Probe is designed with approvals for use in hazardous and explosive environments (CSA, ATEX, IECEx).

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
