Bently Nevada 330106-05-30-50-12-00 | Reverse Mount Probes

Overview

The Bently Nevada 330106-05-30-50-12-00 Reverse Mount Probe is a high-performance sensing device designed for precise temperature measurement in harsh environments. Made in the U.S.A and equipped with various technical features, this probe is ideal for industrial applications where reliability is crucial.

Technical Specifications

• Brand: Bently Nevada (U.S. manufacturing origin)
• Model & Suffix: 330106-05-30-50-12-00
  • 330106-05-30: M10 x 1 threads

  • 50: 5.0m cable length (compatible with 5m Proximitor sensors)
  • 12: Miniature ClickLoc coaxial connector with FluidLoc cable
  • 00: No agency certifications required
• Electrical: DC resistance 8.73Ω ±0.5 (center to outer conductor)
• Mechanical:
  • Case material: AISI 303/304 stainless steel
  • Tip material: Polyphenylene sulfide (PPS)
  • Torque limit: 22.6 N•m (max), 7.5 N•m recommended
• Environmental:
  • Operating range: -52°C to +177°C (extended tip: +218°C, cable: +260°C)
  • Pressure seal: Viton® O-ring (untested; custom testing available)

Applications

• Industrial turbomachinery (turbines, compressors)
• High-vibration environments requiring reverse mounting
• High-temperature process monitoring

Advantages

• Corrosion-resistant stainless steel housing
• Extended thermal tolerance for harsh conditions
• Modular design with configurable cable/connector options

FAQ

• Q1: What is the maximum temperature the 330106 probes can withstand?
  A1: The standard probe can operate up to +177°C, while the extended temperature range allows for +218°C (probe tip) and +260°C (cable and connector).
• Q2: Are these probes tested for pressure before shipment?
  A2: No, probes are not pressure tested prior to shipment. Customers needing a pressure seal test should contact the custom design department.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
