Bently Nevada | 330130-040-00-RU 3300 XL Extension Cable

Overview:

The Bently Nevada 3300 XL Extension Cable (Product No. 330130-040-00-RU) is designed for use with the 3300 XL 8 mm Proximity Sensor. This extension cable features 75 Ω triaxial fluoroethylene propylene (FEP) insulation to ensure durable, high-performance connections in industrial applications. It supports an operating temperature range from -51°C to +177°C (-60°F to +351°F), making it suitable for extreme environments. The cable is available in a variety of lengths, with 4.0 meters (13.1 feet) being one of the available options.

Key Features:

• Cable Length: 4.0 meters (13.1 feet)
• Material: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated
• Weight: 0.45 kg
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Temperature Range: -51°C to +177°C (-60°F to +351°F)
• Connector Type: Standard (00) cable with optional FluidLoc (prevents liquid leakage)
• Agency Approvals: Country-specific (RU) for certifications
• Designed for Use with: 3300 XL 8 mm Proximity Sensor (part of the 3300 XL series)

Technical Specifications:

• Power Requirements: -17.5 Vdc to -26 Vdc (with non-incendive circuit connected per installation drawing 140979); -23 Vdc to -26 Vdc with barriers.
• Linear Range: 2 mm (80 mils); operates between 0.25 mm to 2.3 mm (10 mils to 90 mils)
• Output Resistance: 50 Ω
• Field Wiring: Suitable for cables between 0.2 to 1.5 mm² (16 to 24 AWG), with recommended use of 3-conductor shielded triad cable and tinned field wiring.
• Maximum Cable Length: 305 meters (1,000 feet)
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.

Brand and Model Information:

• Brand: Bently Nevada
• Model: 3300 XL Extension Cable
• Product Number: 330130-040-00-RU
• Suffix Meaning:
  • 040: Cable length of 4.0 meters (13.1 feet)
  • 00: Standard cable type
  • RU: Approvals country-specific

Frequently Asked Questions (FAQ):

• 1. What is the maximum operating temperature of the Bently Nevada 3300 XL Extension Cable?
• The cable can operate in extreme environments with temperatures ranging from -51°C to +177°C (-60°F to +351°F).
• 2. What is the maximum distance allowed for the extension cable between the Proximity Sensor and monitor?
• The maximum recommended length for the extension cable is 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitoring system.
• 4. Can the cable be used in applications involving fluid exposure?
• Yes, the optional FluidLoc cable feature prevents oil and other liquids from leaking through the cable’s interior, making it suitable for use in wet or oily environments.
• 5. How does the Bently Nevada 3300 XL Extension Cable ensure durability?
• The cable utilizes the TipLoc molding method for a robust bond between the probe tip and the probe body, as well as the CableLoc design, which ensures a 330 N (75 lbf) pull strength for secure attachment.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
