Bently Nevada 330130-040-02-05 | 3300 XL Extension Cable

Overview

The Bently Nevada 330130-040-02-05 is a 3300 XL Extension Cable designed for use with Bently Nevada’s 3300 XL 8 mm Proximitor Sensors and probes. Made in the USA, it features 75 Ω triaxial, fluoroethylene propylene (FEP) insulation, ensuring robust and reliable performance in demanding industrial environments. With an operating temperature range from -51 °C to +177 °C (-60 °F to +351 °F), this extension cable is suitable for extreme conditions. Additionally, the extension cable supports a maximum length of 305 meters (1,000 feet) and features a cable capacitance of 69.9 pF/m (21.3 pF/ft), making it ideal for long-distance installations.

The product also incorporates advanced design features such as the TipLoc molding method for secure probe tip attachment, and the CableLoc design that provides a pull strength of up to 330 N (75 lbf), enhancing cable durability and system reliability.

Key Specifications:

• Brand: Bently Nevada
• Model: 330130-040-02-05
• Cable Length: 4.0 meters (13.1 feet)
• Cable Material: 75 Ω triaxial, FEP insulated
• Operating Temperature: -51 °C to +177 °C (-60 °F to +351 °F)
• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Weight: 0.45 kg
• Connector Protector: Yes (Standard)
• Agency Approvals: Multiple
• FluidLoc Cable Option: Available for protection against leakage of oils or other liquids
• Extension Cable Options: Available in lengths of 0.5, 1, 1.5, 2, 5, or 9 meters
• Power Supply Requirement: -17.5 Vdc to -26 Vdc, with a 12 mA maximum current draw

FAQ:

1. What is the typical cable capacitance of the 3300 XL extension cable?
The extension cable typically has a capacitance of 69.9 pF/m (21.3 pF/ft).

2. What is the weight of the 3300 XL extension cable?
The cable weighs approximately 0.45 kg.

3. Can the 3300 XL extension cable be used in extreme temperatures?
Yes, it operates in a wide temperature range of -51 °C to +177 °C (-60 °F to +351 °F).

4. How long can I install the extension cable?
The maximum recommended installation length is 305 meters (1,000 feet) from the sensor to the monitor.

5. Does the cable have an optional FluidLoc feature?
Yes, the cable can be ordered with the optional FluidLoc feature to prevent fluid leakage.

6. What is the power supply requirement for the 3300 XL extension cable?
It requires -17.5 Vdc to -26 Vdc for proper operation.

7. What is the maximum pull strength of the cable’s attachment?
The cable features a 330 N (75 lbf) pull strength for secure attachment.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
