Bently Nevada 330130-040-11-05 | Armored FluidLoc Cable

Overview

The Bently Nevada 3300 XL Standard Extension Cable (Part Number: 330130-040-11-05) is a high-quality, durable cable designed for use with Bently Nevada probes. This extension cable is essential for applications that necessitate reliable connectivity and performance. Manufactured to rigorous standards, it comes in factory packing with a 12-month warranty, ensuring that customers receive a quality product.

Key Features

• Model: 330130-040-11-05
• Brand: Bently Nevada
• Condition: New & Original in Factory Packing
• Warranty: 12 Months

Technical Specifications

• Cable Length: 4.0 meters (11.5 feet)
• Connector Protector and Cable Option: Armored FluidLoc cable
• Agency Approval Options: CSA, ATEX, IECEx
• DC Resistance:
  • Center Conductor (RCORE): 0.88 ± 0.13 Ω for 4.0 m
  • Outer Conductor (RJACKET): 0.26 ± 0.05 Ω for 4.0 m
• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Output Resistance: 50 Ω
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Linear Range: 2 mm (80 mils) with a starting point of 0.25 mm (10 mils) from target
• Power Requirements:
  • -17.5 Vdc to -26 Vdc (12 mA max)
  • -23 Vdc to -26 Vdc with barriers
• Field Wiring:
  • Recommended: 3 conductor shielded triad cable
  • Wire gauge: 0.2 to 1.5 mm² (16 to 24 AWG)
  • Maximum length: 305 meters (1,000 feet)

Frequently Asked Questions (FAQ)

• Q: What is included with the 3300 XL extension cable?
  A: Each extension cable comes with silicone tape for use instead of connector protectors. However, silicone tape is not recommended for applications exposed to turbine oil.
• Q: What environmental conditions do the specifications apply to?
  A: Specifications are applicable for temperatures ranging from +18˚C to +27˚C (+64˚F to +80˚F) at altitudes up to 2000 meters.
• Q: What improvements does this model offer?
  A: The cable features a patented TipLoc molding method for a robust bond and a CableLoc design that ensures high pull strength.
• Q: Can I use this with other target types?
  A: Performance and accuracy specifications apply only to systems calibrated with the AISI 4140 steel target.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
