Bently Nevada 330130-060-03-00 | Armored Extension Cable

Overview:

The Bently Nevada 330130-060-03-00 is a high-performance extension cable designed for the 3300 XL proximity probe system. Manufactured in the USA, this cable offers enhanced durability and flexibility, featuring an armored construction for added protection. It includes a connector protector for secure connections, and a silicone tape option for less demanding environments (note: silicone tape is not recommended for turbine oil exposure). This extension cable has a length of 6.0 meters (19.7 feet) and is suitable for use in various industrial applications.

Technical Specifications:

• Manufacturer: Bently Nevada
• Model Number: 330130-060-03-00
• Cable Length: 6.0 meters (19.7 feet)
• Connector Protector Option: Armored cable with connector protector
• Cable Weight: 0.618 kg
• Cable Weight per Meter: 103 g/m (1.5 oz/ft)
• Made In: U.S.A
• Certificate of Origin (COO): Available upon request

Electrical Characteristics:

• Nominal Extension Cable DC Resistance:
  • Resistance (RCORE) from Center Conductor to Center Conductor: 1.32 ± 0.21 Ω at 6.0 meters
  • Resistance (RJACKET) from Outer Conductor to Outer Conductor: 0.39 ± 0.08 Ω at 6.0 meters
• Capacitance: 69.9 pF/m (21.3 pF/ft), typical
• Power Supply Requirements:
  • -17.5 Vdc to -26 Vdc with non-incendive circuit
  • -23 Vdc to -26 Vdc with barriers (12 mA max consumption)
• Output Resistance: 50 Ω
• Field Wiring:
  • Compatible with 0.2 to 1.5 mm² (16 to 24 AWG) wire
  • Recommend 3-conductor shielded triad cable
• Maximum Field Wiring Length: 305 meters (1,000 feet)

Frequently Asked Questions (FAQ):

1. What is the maximum length of the extension cable?
   • The maximum field wiring length is 305 meters (1,000 feet).
2. What is the voltage requirement for the 330130-060-03-00 extension cable?
   • The cable requires -17.5 Vdc to -26 Vdc when installed with a non-incendive circuit.
3. What type of wiring should be used with this cable?
   • The recommended field wiring is 0.2 to 1.5 mm² (16 to 24 AWG), using shielded triad cable.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
