Bently Nevada | 330130-075-01-CN 3300 XL Extension Cable

Overview

The Bently Nevada 3300 XL Standard Extension Cable (Model 330130-075-01-CN) offers exceptional performance for vibration monitoring systems. This extension cable connects seamlessly to 3300 XL probes, ensuring reliable operation and enhanced durability. With its innovative CableLoc design, the cable provides a strong attachment and superior protection, making it ideal for demanding industrial environments.

Technical Specifications

The following specifications highlight the superior design of the Bently Nevada 3300 XL Standard Extension Cable:

• Brand: Bently Nevada
• Model: 330130-075-01-CN
• Connector Material: Gold-plated brass or gold-plated beryllium copper delivers excellent conductivity and durability.
• Maximum Connector Torque: The cable supports up to 0.565 N•m (5 in•lbf) of torque for a secure connection.
• Cable Type: The 75 Ω triaxial cable uses FEP insulation for standard conditions and PFA insulation for extended temperature ranges.
• Temperature Range:
  • Standard Cable: Operates between -52°C and +177°C (-62°F to +350°F).
  • Extended Temperature Cable: Functions efficiently from -52°C to +260°C (-62°F to +500°F).
• Bend Radius: A minimum bend radius of 25.4 mm (1.0 in) ensures flexibility during installation.
• Pull Strength: The cable withstands up to 330 N (75 lbf) of pull force, ensuring reliability under tension.
• Output Resistance: The 50 Ω resistance guarantees stable and precise signal transmission.
• Voltage Supply: The cable requires a power input between -17.5 Vdc and -26 Vdc, consuming a maximum of 12 mA.
• Sensitivity: The cable minimizes sensitivity to voltage variation, with less than 2 mV of change per volt of input fluctuation.

Frequently Asked Questions (FAQ)

1. What is the maximum cable length available for this model?
This model offers a maximum length of 7.5 meters (24.6 feet), ensuring flexibility for different installations.

2. Can the cable withstand high-temperature environments?
Yes, the extended temperature version is designed to handle environments with temperatures ranging from -52°C to +260°C (-62°F to +500°F).

3. What materials are used for the cable connectors?
The connectors utilize gold-plated brass or gold-plated beryllium copper, ensuring high conductivity and durability.

4. Is silicone tape suitable for use with this cable?
Although silicone tape can secure connections effectively, it is not recommended for turbine oil environments to prevent potential issues.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
