Bently Nevada | 330130-080-00-00 3300 XL Extension Cable

Overview

The Bently Nevada 330130-080-00-00 3300 XL Standard Extension Cable is a robust component designed to enhance performance in vibration monitoring systems. With advanced engineering, it provides exceptional durability and efficiency for industrial applications. Featuring proprietary TipLoc and CableLoc technologies, it offers secure connections and superior pull strength. An optional FluidLoc cable can also be selected to prevent fluid leakage through the cable’s interior.

Technical Specifications

• Brand: Bently Nevada
• Model: 330130-080-00-00
• Suffix Definitions:
  • 080: Cable length of 8.0 meters (26.2 feet).
  • 00 (Connector Protector and Cable Option): Standard cable.
  • 00 (Agency Approval Option): No agency approval required.
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical.
• Linear Range: 2 mm (80 mils), starting at 0.25 mm (10 mils) from the target.
• Power Requirements: -17.5 Vdc to -26 Vdc; 12 mA maximum consumption.
• Output Resistance: 50 Ω.
• Field Wiring: Supports 0.2 to 1.5 mm² (16 to 24 AWG) shielded triad cables.

Frequently Asked Questions (FAQ)

Q1: What does the suffix “080” represent in the model number?
The “080” suffix indicates the cable length, which is 8.0 meters or 26.2 feet.

Q2: What are the benefits of the FluidLoc option?
The FluidLoc option prevents oil and other fluids from escaping through the cable, making it suitable for environments prone to fluid leakage.

Q3: Is agency approval available for this model?
This specific model does not require agency approval as indicated by the “00” suffix.

Q4: What are the maximum field wiring specifications?
The maximum field wiring length is 305 meters (1,000 feet), using a 3-conductor shielded triad cable.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
