Bently Nevada 330130-085-00-CN | 3300 XL Extension Cable

Overview

The Bently Nevada 330130-085-00-CN is a 3300 XL Extension Cable to provide superior performance and durability in industrial monitoring systems. With advanced features such as TipLoc molding and CableLoc design, this cable ensures a robust bond and high pull strength, enhancing reliability in demanding environments. Additionally, it is compatible with the 3300 XL 8 mm Proximitor Sensor, offering precise performance when used within specified configurations.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL Extension Cable
• Suffix Definitions:
  • 085: Cable length of 8.5 meters (27.9 feet)
  • 00: Standard cable with no special protection
  • CN: Country-specific agency approvals
• Made in: U.S.A
• Operating and Storage Temperature:
  • Standard Cable: -51 °C to +177 °C (-60 °F to +351 °F)
• Weight: 0.948 kg

Electrical Characteristics

• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Field Wiring Support: 0.2 to 1.5 mm² (16 to 24 AWG)
• Power Supply Requirements: -17.5 Vdc to -26 Vdc
• Output Resistance: 50 Ω
• Sensitivity to Voltage Supply: Less than 2 mV change per volt of input change

Performance Highlights

• Linear Range: 2 mm (80 mils) starting from 0.25 mm (10 mils)
• Maximum Cable Length: Up to 305 meters (1,000 feet) when paired with a 3300 XL Proximitor Sensor

FAQs

1. What does the suffix “085-00-CN” mean?
   • “085” refers to the cable length (8.5 meters), “00” denotes a standard cable, and “CN” indicates country-specific agency approvals.
2. Can this cable be used in high-temperature environments?
   • Yes, the standard cable operates reliably between -51 °C and +177 °C (-60 °F to +351 °F).
3. Is the FluidLoc option included with this product?
   • No, the 330130-085-00-CN features a standard cable. However, FluidLoc is available as an optional feature on other models.
4. What is the recommended wiring type?
   • A 3-conductor shielded triad cable with tinned field wiring is recommended for optimal performance.
5. How does the CableLoc design benefit users?
   • It enhances durability by ensuring a secure attachment between the probe cable and tip, reducing the risk of disconnection.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
