Bently Nevada | 330190-085-00-05 ETR Extension Cable

Overview:

The Bently Nevada 3300 XL 8mm Proximity Transducer System (Model: 330190-085-00-05) is a high-performance system designed for reliable and precise vibration monitoring. This system includes a probe with enhanced durability and an extension cable that offers exceptional pull strength. The patented TipLoc molding method ensures a stronger bond between the probe tip and body. Additionally, the CableLoc design guarantees a secure connection, with a pull strength of 330 N (75 lbf). An optional FluidLoc cable prevents leakage of oil and other liquids, making it ideal for harsh industrial environments.

Key Features:

• Durable Construction: The system features a robust design with patented TipLoc and CableLoc technologies, ensuring long-lasting performance and stability in challenging conditions.
• Cable Length Option: 8.5 meters (27.9 feet) of cable, with the standard cable option for reliable connections.
• Agency Approvals: CSA, ATEX, and IECEx certifications ensure compliance with industry safety standards.
• Temperature Range: The standard probe operates from -52°C to +177°C (-62°F to +350°F), while the extended temperature range option covers -52°C to +218°C for the probe tip and -51°C to +260°C for the cable.
• High-Accuracy Measurement: Designed for systems that require accuracy with a 10 kΩ load and AISI 4140 steel target for calibration.

Technical Specifications:

• Manufacturer: Bently Nevada
• Product Number: 330190-085-00-05
• Model: 3300 XL 8mm Proximity Transducer System
• Weight: 0.323 Kg
• Cable Length: 8.5 meters (27.9 feet)
• Agency Approvals: CSA, ATEX, IECEx
• Power Supply: Requires -17.5 Vdc to -26 Vdc for standard circuits; -23 Vdc to -26 Vdc with barriers
• Sensitivity: Less than 2 mV change per volt of input voltage
• Output Resistance: 50 Ω
• Material: Polyphenylene sulfide (PPS) for probe tip

FAQs:

1. What is the cable length option for this system?
   • The cable length is 8.5 meters (27.9 feet), ideal for most industrial applications.
2. What certifications does this proximity sensor have?
   • It is CSA, ATEX, and IECEx approved, ensuring high safety standards.
3. What temperature ranges can the system withstand?
   • The standard probe operates between -52°C to +177°C, with an extended option reaching -52°C to +218°C for the probe tip and -51°C to +260°C for the cable.
4. How does the FluidLoc cable option work?
   • The FluidLoc option prevents fluids, such as oil, from leaking into the machine through the probe cable, enhancing reliability in liquid-sensitive environments.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
