Bently Nevada 330500-00-01 Velomitor Piezo-velocity Sensor

0 Reviews
10 in stock
  • 100% genuine products in stock with fast delivery.
  • 30-day return policy for quality assurance.
  • 12-month warranty for peace of mind.
SKU: 330500-00-01

Product details

Overview

Bently Nevada’s Velomitor Piezo-velocity Sensor (Product No. 330500-00-01) is an advanced sensor designed for precision vibration measurement. Made in the USA, this sensor features a robust 316L stainless steel case and a 2-pin Mil-C-5015 hermetically sealed connector, ensuring durability and reliability in various environments.

330500-00-01 Technical Specifications

  • Polarity: Pin A becomes positive with respect to pin B when the sensor case motion is towards the connector
  • Sensitivity: 3.94mV/mm/s (100 mV/in/s) Ā±5%
  • Frequency Response:
    • 4.5 Hz to 5 kHz (270 cpm to 300 kcpm) Ā±3.0 dB
    • 6.0 Hz to 2.5 kHz (360 cpm to 150 kcpm) Ā±0.9 dB
  • Temperature Sensitivity: -14% to +7.5% over the operating temperature range
  • Velocity Range: 1270 mm/s (50 in/s) peak
  • Transverse Sensitivity: Less than 5% of sensitivity
  • Amplitude Linearity: Ā±2% to 152 mm/s (6 in/s) peak
  • Mounted Resonant Frequency: Greater than 12 kHz
  • Output Bias Voltage: -12 Ā±3.0 VDC, referenced to Pin A
  • Dynamic Output Impedance: Less than 2400 ā„¦
  • Broadband Noise Floor: 0.004 mm/s (160 Ī¼in/s) rms
  • Grounding: Case isolated
  • Maximum Cable Length: 305 metres (1,000 feet) with no signal degradation

Environmental Limits

  • Operating Temperature Range: -55Ā°C to 121Ā°C (-67Ā°F to 250Ā°F)
  • Shock Survivability: 5,000 g peak
  • Relative Humidity: 100% non-submerged; case hermetically sealed
  • Base Strain Sensitivity: 0.005 in/s/Āµstrain
  • Magnetic Field Susceptibility: <51 Āµin/s/gauss

FAQs

  • Q: Can the sensor be used in extremely hot or cold environments?
    • A: Yes, it operates effectively within the temperature range of -55Ā°C to 121Ā°C (-67Ā°F to 250Ā°F).
  • Q: Is the sensor resistant to shock?
    • A: Absolutely, it can withstand shocks up to 5,000 g peak.
  • Q: What is the maximum cable length that can be used without signal degradation?
    • A: The maximum cable length is 305 metres (1,000 feet).

For more detail information: 330500-Datasheet

Additional information

Weight 0.1 kg
Dimensions 23 × 23 × 59 mm
Country Of Origin

United States
