Bently Nevada 330730-040-01-00 | Armored Extension Cable

Overview

The Bently Nevada 3300 XL 11mm Extension Cable (Part No. 330730-040-01-00) is designed for use with 3300 XL proximity probes in industrial settings. It offers reliable, high-performance capabilities in tough environments. The extension cable is armored with optional flexible AISI 302 stainless steel, providing protection against mechanical stress and environmental hazards. Manufactured in the USA, this extension cable ensures durability, reliability, and excellent signal integrity.

Technical Specifications:

• Brand: Bently Nevada
• Product Type: Extension Cable
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Connector: Gold-plated brass connectorset
• Tensile Strength: 330 N (75 lbs) at probe case to probe lead; 270 N (60 lbs) at probe lead to extension cable connectors
• Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG), recommended three-conductor shielded triad cable
• Frequency Response: Maximum cable length of 305 meters (1,000 feet) for optimal performance

Ordering Information:

• Product No.: 330730-040-01-00
• Cable Length: 4.0 meters (13.1 feet)
• Connector Option: Gold-plated brass
• Cable Armor Option: Flexible AISI 302 SST with FEP jacket (optional)
• Temperature Range: -52°C to +177°C (-62°F to +351°F)
• Tensile Strength: Rated at 330 N (75 lbs)

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
