Bently Nevada 330730-040-02-05 | 3300 XL Extension Cable

Overview

The Bently Nevada 330730-040-02-05 3300 XL 11 mm Extension Cable is designed for use with 3300 XL Proximitor Sensors, providing a reliable and durable connection in harsh industrial environments. The cable features flexible AISI 302 stainless steel armor with a FEP outer jacket, ensuring enhanced protection against external elements. Available with multiple approvals, it offers a high-performance solution for vibration monitoring in machinery. The product is made in the U.S.A and is designed to operate under extreme temperature ranges from -51°C to +177°C (-60°F to +351°F).

Technical Specifications

• Brand: Bently Nevada
• Model: 330730-040-02-05
• Product Type: 3300 XL 11 mm Extension Cable
• Connector: Gold-plated brass with a connector protector for environmental protection
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Extension Cable Armor: Optional flexible AISI 302 SST with FEP outer jacket
• Tensile Strength: 330 N (75 lbs) probe case to probe lead, 270 N (60 lbs) at probe lead to extension cable connectors
• Operating and Storage Temperature: -51°C to +177°C (-60°F to +351°F)
• Resistance:
  • RCORE: 1.0 ± 0.25 ohms (from center conductor to center conductor)
  • RJACKET: 0.3 ± 0.1 ohms (from coaxial conductor to coaxial conductor)
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Linear Range: 0.5 mm (20 mils) to 4.5 mm (180 mils)
• Extended DSL Range: 0.5 mm (20 mils) to 5.0 mm (200 mils)
• Connector Material: Gold-plated brass
• Recommended Gap Setting: 2.5 mm (100 mils)
• Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG), recommended using three-conductor shielded triad cable
• FluidLoc Cable Option: Available to prevent leakage from oil or liquids

Ordering Information

• Model: 330730-040-02-05
  • 040: Cable length of 4.0 meters (13.1 feet)
  • 02: Standard cable with connector protector
  • 05: Multiple agency approvals

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
