Bently Nevada | 330876-02-10-00-00 3300 XL Proximity Probe

Overview

The Bently Nevada 330876-02-10-00-00 3300 XL 50 mm Proximity Probe is engineered for robust performance in demanding steam turbine environments. Its high-temperature FluidLoc cable ensures durability in extreme conditions, while ClickLoc connectors provide secure and contamination-free connections. Designed for precise measurement, this probe delivers reliable data in critical industrial applications.

Features

1. High-Temperature Tolerance: Operates continuously up to 200°C (392°F) and withstands peaks of 250°C (482°F).
2. FluidLoc Cable: Prevents moisture ingress for extended reliability in harsh environments.
3. ClickLoc Connectors: Facilitates easy routing and ensures contamination-free connections.
4. Enhanced Sealing: Dual seals prevent damage from moisture at the probe tip.
5. Compact Design: Straight exit style with M14x1.5 metric threads for secure installation.
6. Connector Protectors: Includes disposable installation tools for clean, contaminant-free setup.

Technical Specifications

• Brand & Model: Bently Nevada 330876-02-10-00-00
• Suffix Meaning:
  • 02: Metric thread type (M14x1.5).
  • 10: Total cable length of 1.0 meter (3.3 feet).
  • 00: High-Temperature FluidLoc cable without additional approvals.
• Power Requirements: Operates on -17.5 to -26 Vdc; 12 mA max consumption.
• Output Resistance: 50 Ω
• Linear Range: 27.9 mm (1100 mils) starting at 1.3 mm (50 mils).
• Material: 75 Ω triaxial PFA insulated FluidLoc cable.
• Deviation from Best Fit Line: ±0.74 mm (29 mils).
• Target Compatibility: Minimum target size of 102 mm (4.0 inches) in diameter.
• Temperature Range: Probe from -35°C to +120°C (-31°F to +248°F).
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft).

Applications

• Steam Turbines: High-temperature performance in harsh environments.
• Industrial Machinery: Suitable for precision monitoring and condition assessment.
• Critical Systems: Ensures operational reliability in moisture-prone and high-temperature areas.

FAQ

1. What is the primary use of the 3300 XL 50 mm Proximity Probe?
This probe is designed for precise proximity measurements in industrial applications, especially steam turbines and rotating machinery.

2. Does the probe work in high-temperature conditions?
Yes, it can continuously operate at 200°C (392°F) and withstand intermittent peaks of 250°C (482°F).

3. What is the significance of the FluidLoc cable?
The FluidLoc cable prevents moisture ingress, ensuring consistent performance in humid or high-moisture environments.

4. Are installation tools included?
Yes, each probe includes connector protectors and disposable installation tools for contamination-free setup.

5. What voltage range is required for operation?
The probe requires -17.5 Vdc to -26 Vdc without barriers or -23 Vdc to -26 Vdc with barriers.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
