Bently Nevada | 330876-02-50-00-05 3300 XL Proximity Probe

Overview:

The Bently Nevada 3300 XL 50 mm Proximity Probe, model 330876-02-50-00-05, is designed for reliable operation in challenging industrial environments, such as steam turbines. With its ability to withstand extreme temperatures and its precise measurement capabilities, this probe is ideal for high-performance vibration monitoring systems.

Technical Specifications:

• Model: 3300 XL 50 mm Proximity Probe
• Product Number: 330876-02-50-00-05
• Thread Type: M14x1.5
• Length: 5 meters (16.4 feet)
• Cable: High Temperature FluidLoc cable
• Weight: 0.59 Kg
• Power Requirements: -17.5 Vdc to -26 Vdc (without barriers), -23 Vdc to -26 Vdc (with barriers)
• Linear Range: 27.9 mm (1100 mils)
• Average Scale Factor (ASF): 394 mV/mm (10 mV/mil)
• Deviation from Best Fit Line: ±0.74 mm (±29 mils)
• Target Size: Minimum 102 mm (4.0 in) diameter flat target
• Cable Material: 75 Ω triaxial, PFA insulated FluidLoc cable

FAQ:

1. What is the maximum operating temperature for the 3300 XL probe?
   The 3300 XL probe can operate in continuous temperatures up to 200°C (392°F), withstanding intermittent temperatures as high as 250°C (482°F).
2. What kind of cable does the probe use?
   The probe uses a high-temperature FluidLoc cable with a 75 Ω triaxial, PFA-insulated material for durability and high performance in extreme conditions.
3. What thread types are available for the 3300 XL probe?
   The 3300 XL probe is available in both ½-20 English threads and M14x1.5 metric threads, providing flexibility for different installation requirements.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
